1IQK

Human coagulation factor Xa in complex with M55113


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.20 Å
  • R-Value Free: 0.280
  • R-Value Work: 0.172

wwPDB Validation   3D Report Full Report


This is version 1.5 of the entry. See complete history


Literature

Factor Xa Specific Inhibitor that Induces the Novel Binding Model in Complex with Human Fxa

Matsusue, T.Shiromizu, I.Okamoto, A.Nakayama, K.Nishida, H.Mukaihira, T.Miyazaki, Y.Saitou, F.Morishita, H.Ohnishi, S.Mochizuki, H.

To be published.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
coagulation Factor Xa235Homo sapiensMutation(s): 0
EC: 3.4.21.6
UniProt & NIH Common Fund Data Resources
Find proteins for P00742 (Homo sapiens)
Explore P00742
Go to UniProtKB:  P00742
PHAROS:  P00742
GTEx:  ENSG00000126218
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00742
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
coagulation Factor XaB [auth L]96Homo sapiensMutation(s): 0
EC: 3.4.21.6
UniProt & NIH Common Fund Data Resources
Find proteins for P00742 (Homo sapiens)
Explore P00742
Go to UniProtKB:  P00742
PHAROS:  P00742
GTEx:  ENSG00000126218
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00742
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
XMI
Query on XMI

Download Ideal Coordinates CCD File
D [auth A]4-[(6-CHLORO-2-NAPHTHALENYL)SULFONYL]-1-[[1-(4-PYRIDINYL)-4-PIPERIDINYL]METHYL]PIPERAZINONE
C25 H27 Cl N4 O3 S
BKWIJYNQPXKNMH-UHFFFAOYSA-N
CA
Query on CA

Download Ideal Coordinates CCD File
C [auth A]CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.20 Å
  • R-Value Free: 0.280
  • R-Value Work: 0.172
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 71.96α = 90
b = 78.92β = 90
c = 56.14γ = 90
Software Package:
Software NamePurpose
GLRFphasing
CNXrefinement

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2003-09-23
    Type: Initial release
  • Version 1.1: 2007-11-21
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Derived calculations, Version format compliance
  • Version 1.3: 2017-10-04
    Changes: Refinement description
  • Version 1.4: 2023-12-27
    Changes: Data collection, Database references, Derived calculations
  • Version 1.5: 2024-10-09
    Changes: Structure summary
