1I9E

TCR DOMAIN


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free: 0.233
  • R-Value Work: 0.203
  • R-Value Observed: 0.206

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Crystal structure of an isolated V(alpha) domain of the 2C T-cell receptor.

Rudolph, M.G.Huang, M.Teyton, L.Wilson, I.A.

(2001) J Mol Biol 314: 1-8

  • DOI: 10.1006/jmbi.2001.5113
  • Structures With Same Primary Citation

  • PubMed Abstract:
  • The T-cell receptor (TCR) is a heterodimeric cell-surface protein consisting of two chains, alpha and beta, each of which is composed of a variable (V) and a constant (C) domain. Crystals of the isolated V(alpha) domain of the murine TCR 2C were grow ...

    The T-cell receptor (TCR) is a heterodimeric cell-surface protein consisting of two chains, alpha and beta, each of which is composed of a variable (V) and a constant (C) domain. Crystals of the isolated V(alpha) domain of the murine TCR 2C were grown by serendipity from a solution containing the extracellular domains of the intact TCR 2C and CD3 gamma epsilon-chains. The V(alpha) crystal structure shows how crystal packing can substitute for another V(alpha) domain in a different fashion from that observed in V(alpha)/V(alpha) homodimer and V(alpha)/V(beta) heterodimer structures. Significant conformational changes occur in the CDR3 and beta(3)beta(4) loops that normally form part of the dimer interface. The monomeric V(alpha) domain provides the unique opportunity to study the effect of dimerization on the conformation of the unliganded complementarity-determining regions (CDR) of a TCR. This structure of an individual V(alpha) module has implications for stability and bioengineering of isolated antibody and immunoglobulin domains.


    Organizational Affiliation

    Department of Molecular Biology and Skaggs Institute for Chemical Biology (BCC-206), The Scripps Research Institute, 10550 North Torrey Pines Road, La Jolla, CA 92037, USA.



Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
CYTOTOXIC TCELL VALPHA DOMAIN
A
115Mus musculusMutation(s): 0
Find proteins for P01738 (Mus musculus)
Go to UniProtKB:  P01738
Protein Feature View
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
NAG
Query on NAG

Download CCD File
A
N-ACETYL-D-GLUCOSAMINE
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free: 0.233
  • R-Value Work: 0.203
  • R-Value Observed: 0.206
  • Space Group: I 41 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 104.032α = 90
b = 104.032β = 90
c = 63.09γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
AMoREphasing
REFMACrefinement

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2001-12-05
    Type: Initial release
  • Version 1.1: 2008-04-27
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Advisory, Refinement description, Version format compliance
