1GN6

G152A mutant of Mycobacterium tuberculosis iron-superoxide dismutase.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.9 Å
  • R-Value Work: 0.169

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

X-Ray Structure Analysis of an Engineered Fe-Superoxide Dismutase Gly-Ala Mutant with Significantly Reduced Stability to Denaturant

Cooper, J.B.Saward, S.Erskine, P.T.Badasso, M.O.Wood, S.P.Zhang, Y.Young, D.B.

(1996) FEBS Lett. 387: 105


  • PubMed Abstract:
  • We have refined the X-ray structure of a site-directed G152A mutant of the iron-dependent superoxide dismutase from Mycobacterium tuberculosis at 2.9 angstroms resolution. The mutation which replaces a glycine residue in a surface loop with alanine w ...

    We have refined the X-ray structure of a site-directed G152A mutant of the iron-dependent superoxide dismutase from Mycobacterium tuberculosis at 2.9 angstroms resolution. The mutation which replaces a glycine residue in a surface loop with alanine was designed to alter the conformation of this loop region which has previously been shown to play a crucial structural role in quaternary interactions within the SOD tetramer. Gly-152 was targeted as it has dihedral angles (phi = 83.1 degrees, psi = -0.3 degrees) close to the left-handed alpha-helical conformation which is rarely adopted by other amino acids except asparagine. Gly-152 was replaced by alanine as it has similar size and polarity, yet has a very low tendency to adopt similar conformations. X-ray data collection on crystals of this mutant at 2.9 angstroms resolution and subsequent least-squares refinement to an R-value of 0.169 clearly establish that the loop conformation is unaffected. Fluorescence studies of guanidine hydrochloride denaturation establish that the mutant is 4 kcal/mol less stable than the wild-type enzyme. Our results indicate that strict conformational constraints imposed upon a region of polypeptide, due for example to interactions with a neighbouring subunit, may force an alanine residue to adopt this sterically hindered conformation with a consequent reduction in stability of the folded conformation.


    Organizational Affiliation

    Department of Crystallography, Birkbeck College, University of London, UK.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
SUPEROXIDE DISMUTASE
A, B, C, D
207Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv)Gene Names: sodB (sod, sodA)
EC: 1.15.1.1
Find proteins for P9WGE7 (Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv))
Go to UniProtKB:  P9WGE7
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
FE
Query on FE

Download SDF File
Download CCD File
A, B, C, D
FE (III) ION
Fe
VTLYFUHAOXGGBS-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.9 Å
  • R-Value Work: 0.169
  • Space Group: P 1 21 1
Unit Cell:
Length (Å)Angle (°)
a = 68.700α = 90.00
b = 85.600β = 99.80
c = 66.700γ = 90.00
Software Package:
Software NamePurpose
CCP4phasing
CCP4refinement
SCALAdata scaling
MOSFLMdata reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2001-10-05
    Type: Initial release
  • Version 1.1: 2011-05-08
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
