1GK1

Structure-based prediction of modifications in glutarylamidase to allow single-step enzymatic production of 7-aminocephalosporanic acid from cephalosporin C


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free: 0.219
  • R-Value Work: 0.180
  • R-Value Observed: 0.180

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

Structure-Based Prediction of Modifications in Glutarylamidase to Allow Single-Step Enzymatic Production of 7-Aminocephalosporanic Acid from Cephalosporin C.

Fritz-Wolf, K.Koller, K.P.Lange, G.Liesum, A.Sauber, K.Schreuder, H.Aretz, W.Kabsch, W.

(2002) Protein Sci 11: 92

  • DOI: https://doi.org/10.1110/ps.27502
  • Primary Citation of Related Structures:
    1GK0, 1GK1

  • PubMed Abstract:

    Glutarylamidase is an important enzyme employed in the commercial production of 7-aminocephalosporanic acid, a starting compound in the synthesis of cephalosporin antibiotics. 7-aminocephalosporanic acid is obtained from cephalosporin C, a natural antibiotic, either chemically or by a two-step enzymatic process utilizing the enzymes D-amino acid oxidase and glutarylamidase. We have investigated possibilities for redesigning glutarylamidase for the production of 7-aminocephalosporanic acid from cephalosporin C in a single enzymatic step. These studies are based on the structures of glutarylamidase, which we have solved with bound phosphate and ethylene glycol to 2.5 A resolution and with bound glycerol to 2.4 A. The phosphate binds near the catalytic serine in a way that mimics the hemiacetal that develops during catalysis, while the glycerol occupies the side-chain binding pocket. Our structures show that the enzyme is not only structurally similar to penicillin G acylase but also employs essentially the same mechanism in which the alpha-amino group of the catalytic serine acts as a base. A subtle difference is the presence of two catalytic dyads, His B23/Glu B455 and His B23/Ser B1, that are not seen in penicillin G acylase. In contrast to classical serine proteases, the central histidine of these dyads interacts indirectly with the O(gamma) through a hydrogen bond relay network involving the alpha-amino group of the serine and a bound water molecule. A plausible model of the enzyme-substrate complex is proposed that leads to the prediction of mutants of glutarylamidase that should enable the enzyme to deacylate cephalosporin C into 7-aminocephalosporanic acid.


  • Organizational Affiliation

    Department of Biophysics, Max-Planck Institute for Medical Research, Jahnstr. 29, D-69120 Heidelberg, Germany. fritz@mpimf-heidelberg.mpg.de


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
CEPHALOSPORIN ACYLASE
A, C
153Pseudomonas sp.Mutation(s): 0
EC: 3.5.1.11
UniProt
Find proteins for P07662 (Pseudomonas sp. (strain SY-77))
Explore P07662
Go to UniProtKB:  P07662
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP07662
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
CEPHALOSPORIN ACYLASE
B, D
522Pseudomonas sp.Mutation(s): 0
EC: 3.5.1.11
UniProt
Find proteins for P07662 (Pseudomonas sp. (strain SY-77))
Explore P07662
Go to UniProtKB:  P07662
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP07662
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free: 0.219
  • R-Value Work: 0.180
  • R-Value Observed: 0.180
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 230.29α = 90
b = 70.44β = 97.48
c = 114.8γ = 90
Software Package:
Software NamePurpose
CNSrefinement
XDSdata reduction
XDSdata scaling
XSCALEdata scaling
CNSphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2002-01-01
    Type: Initial release
  • Version 1.1: 2011-09-07
    Changes: Data collection, Database references, Derived calculations, Non-polymer description, Other, Refinement description, Structure summary, Version format compliance
  • Version 1.2: 2017-06-28
    Changes: Data collection
  • Version 1.3: 2019-05-08
    Changes: Data collection, Experimental preparation
  • Version 1.4: 2023-12-13
    Changes: Data collection, Database references, Derived calculations, Other, Refinement description
