1GAT

SOLUTION STRUCTURE OF THE SPECIFIC DNA COMPLEX OF THE ZINC CONTAINING DNA BINDING DOMAIN OF THE ERYTHROID TRANSCRIPTION FACTOR GATA-1 BY MULTIDIMENSIONAL NMR


Experimental Data Snapshot

  • Method: SOLUTION NMR
  • Conformers Submitted:

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

NMR structure of a specific DNA complex of Zn-containing DNA binding domain of GATA-1.

Omichinski, J.G.Clore, G.M.Schaad, O.Felsenfeld, G.Trainor, C.Appella, E.Stahl, S.J.Gronenborn, A.M.

(1993) Science 261: 438-446

  • DOI: 10.1126/science.8332909
  • Primary Citation of Related Structures:
    1GAU, 1GAT

  • PubMed Abstract:
  • The three-dimensional solution structure of a complex between the DNA binding domain of the chicken erythroid transcription factor GATA-1 and its cognate DNA site has been determined with multidimensional heteronuclear magnetic resonance spectroscopy ...

    The three-dimensional solution structure of a complex between the DNA binding domain of the chicken erythroid transcription factor GATA-1 and its cognate DNA site has been determined with multidimensional heteronuclear magnetic resonance spectroscopy. The DNA binding domain consists of a core which contains a zinc coordinated by four cysteines and a carboxyl-terminal tail. The core is composed of two irregular antiparallel beta sheets and an alpha helix, followed by a long loop that leads into the carboxyl-terminal tail. The amino-terminal part of the core, including the helix, is similar in structure, although not in sequence, to the amino-terminal zinc module of the glucocorticoid receptor DNA binding domain. In the other regions, the structures of these two DNA binding domains are entirely different. The DNA target site in contact with the protein spans eight base pairs. The helix and the loop connecting the two antiparallel beta sheets interact with the major groove of the DNA. The carboxyl-terminal tail, which is an essential determinant of specific binding, wraps around into the minor groove. The complex resembles a hand holding a rope with the palm and fingers representing the protein core and the thumb, the carboxyl-terminal tail. The specific interactions between GATA-1 and DNA in the major groove are mainly hydrophobic in nature, which accounts for the preponderance of thymines in the target site. A large number of interactions are observed with the phosphate backbone.


    Organizational Affiliation

    Laboratory of Chemical Physics, National Institute of Diabetes and Digestive and Kidney Diseases, National Institutes of Health, Bethesda, MD 20892.



Macromolecules

Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetailsImage
ERYTHROID TRANSCRIPTION FACTOR GATA-1A60Gallus gallusMutation(s): 0
Gene Names: GATA1ERYF1
Find proteins for P17678 (Gallus gallus)
Explore P17678
Go to UniProtKB:  P17678
Protein Feature View
Expand
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
  • Find similar nucleic acids by:  Sequence   |   Structure
  • Entity ID: 1
    MoleculeChainsLengthOrganismImage
    DNA (5'-D(P*AP*GP*AP*TP*AP*AP*AP*C)3')B8N/A
    • Find similar nucleic acids by:  Sequence   |   Structure
    • Entity ID: 2
      MoleculeChainsLengthOrganismImage
      DNA (5'-D(P*GP*TP*TP*TP*AP*TP*CP*T)-3')C8N/A
      Small Molecules
      Ligands 1 Unique
      IDChainsName / Formula / InChI Key2D Diagram3D Interactions
      ZN
      Query on ZN

      Download CCD File
      A
      ZINC ION
      Zn
      PTFCDOFLOPIGGS-UHFFFAOYSA-N
       Ligand Interaction
      Experimental Data & Validation

      Experimental Data

      • Method: SOLUTION NMR
      • Conformers Submitted:
      • OLDERADO: 1GAT Olderado

      Structure Validation

      View Full Validation Report



      Entry History

      Deposition Data

      Revision History

      • Version 1.0: 1993-10-31
        Type: Initial release
      • Version 1.1: 2008-03-24
        Changes: Version format compliance
      • Version 1.2: 2011-07-13
        Changes: Version format compliance
      • Version 1.3: 2012-09-05
        Changes: Database references
