1G2J

RNA OCTAMER R(CCCP*GGGG) CONTAINING PHENYL RIBONUCLEOTIDE


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.97 Å
  • R-Value Free: 0.269
  • R-Value Work: 0.217

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Crystal structure of an RNA duplex containing phenyl-ribonucleotides, hydrophobic isosteres of the natural pyrimidines.

Minasov, G.Matulic-Adamic, J.Wilds, C.J.Haeberli, P.Usman, N.Beigelman, L.Egli, M.

(2000) RNA 6: 1516-1528


  • PubMed Abstract:
  • Chemically modified nucleotide analogs have gained widespread popularity for probing structure-function relationships. Among the modifications that were incorporated into RNAs for assessing the role of individual functional groups, the phenyl nucleot ...

    Chemically modified nucleotide analogs have gained widespread popularity for probing structure-function relationships. Among the modifications that were incorporated into RNAs for assessing the role of individual functional groups, the phenyl nucleotide has displayed surprising effects both in the contexts of the hammerhead ribozyme and pre-mRNA splicing. To examine the conformational properties of this hydrophobic base analog, we determined the crystal structure of an RNA double helix with incorporated phenyl ribonucleotides at 1.97 A resolution. In the structure, phenyl residues are engaged in self-pairing and their arrangements suggest energetically favorable stacking interactions with 3'-adjacent guanines. The presence of the phenyl rings in the center of the duplex results in only moderate changes of the helical geometry. This finding is in line with those of earlier experiments that showed the phenyl analog to be a remarkably good mimetic of natural base function. Because the stacking interactions displayed by phenyl residues appear to be similar to those for natural bases, reduced conformational restriction due to the lack of hydrogen bonds with phenyl as well as alterations in its solvent structure may be the main causes of the activity changes with phenyl-modified RNAs.


    Organizational Affiliation

    Department of Molecular Pharmacology and Biological Chemistry and The Drug Discovery Program, Northwestern University Medical School, Chicago, Illinois 60611, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsLengthOrganism
5'-R(*CP*CP*CP*(PYY)P*GP*GP*GP*G)-3'A8N/A
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
CA
Query on CA

Download SDF File
Download CCD File
A
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
PYY
Query on PYY
A
RNA LINKINGC11 H15 O7 P

--

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.97 Å
  • R-Value Free: 0.269
  • R-Value Work: 0.217
  • Space Group: P 61 2 2
Unit Cell:
Length (Å)Angle (°)
a = 24.310α = 90.00
b = 24.310β = 90.00
c = 123.790γ = 120.00
Software Package:
Software NamePurpose
DENZOdata reduction
AMoREphasing
CNSrefinement
SCALEPACKdata scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2000-12-06
    Type: Initial release
  • Version 1.1: 2008-04-27
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
