1G1Y | pdb_00001g1y

CRYSTAL STRUCTURE OF ALPHA-AMYLASE II (TVAII) FROM THERMOACTINOMYCES VULGARIS R-47 AND BETA-CYCLODEXTRIN COMPLEX


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.00 Å
  • R-Value Free:
    0.260 (Depositor)
  • R-Value Work:
    0.191 (Depositor), 0.196 (DCC)
  • R-Value Observed:
    0.198 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 1G1Y

This is version 2.2 of the entry. See complete history

Literature

Studies on the hydrolyzing mechanism for cyclodextrins of Thermoactinomyces vulgaris R-47 alpha-amylase 2 (TVAII). X-ray structure of the mutant E354A complexed with beta-cyclodextrin, and kinetic analyses on cyclodextrins.

Kondo, S.Ohtaki, A.Tonozuka, T.Sakano, Y.Kamitori, S.

(2001) J Biochem 129: 423-428

  • DOI: https://doi.org/10.1093/oxfordjournals.jbchem.a002873
  • Primary Citation Related Structures:
    1G1Y

  • PubMed Abstract:

    Crystals of the mutant E354A of Thermoactinomyces vulgaris R-47 alpha-amylase 2 (TVAII) complexed with beta-cyclodextrin were prepared by a soaking method, and the diffraction data were collected at 100 K, using Synchrotron radiation (SPring-8). The crystals belong to an orthorhombic system with the space group P2(1)2(1)2(1) and cell dimensions a = 111.1 A, b = 117.7 A, c = 113.3 A, which is almost isomorphous with crystals of the wild-type TVAII, and the structure was refined to an R-factor = 0.208 (R(free) = 0.252) using 3.0 A resolution data. The refined structure shows that the interactions between Phe286 and two C6 atoms of beta-cyclodextrin at the hydrolyzing site are important for TVAII to recognize cyclodextrins as substrates. This observation from the X-ray structure was supported by kinetic analyses of cyclodextrins using the wild-type TVAII, the mutant F286A and F286L. These studies also suggested that the TVAII-hydrolyzing mechanism for cyclodextrins is slightly different from that for starch.


  • Organizational Affiliation
    • Department of Biotechnology & Life Science, Tokyo University of Agriculture & Technology, Naka-cho, Koganei, Tokyo 184-8588, Japan.

Macromolecule Content

  • Total Structure Weight: 137.3 kDa
  • Atom Count: 10,221
  • Modeled Residue Count: 1,170
  • Deposited Residue Count: 1,170
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
ALPHA-AMYLASE II
A, B
585Thermoactinomyces vulgarisMutation(s): 1
EC: 3.2.1.135
UniProt
Find proteins for Q08751 (Thermoactinomyces vulgaris)
Explore Q08751
Go to UniProtKB:  Q08751
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ08751
Sequence Annotations
Expand
Reference Sequence

Oligosaccharides

Help
Entity ID: 2
MoleculeChains Length2D Diagram GlycosylationD Interactions
Cycloheptakis-(1-4)-(alpha-D-glucopyranose)
C, D
7N/A
Glycosylation Resources
GlyTouCan: G01435GL
GlyCosmos: G01435GL

Biologically Interesting Molecules (External Reference)

1 Unique

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.00 Å
  • R-Value Free:  0.260 (Depositor)
  • R-Value Work:  0.191 (Depositor), 0.196 (DCC)
  • R-Value Observed: 0.198 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 111.12α = 90
b = 117.66β = 90
c = 113.27γ = 90
Software Package:
Software NamePurpose
X-PLORmodel building
X-PLORrefinement
MOSFLMdata reduction
CCP4data scaling
X-PLORphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2001-03-14
    Type: Initial release
  • Version 1.1: 2008-04-27
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Advisory, Atomic model, Data collection, Derived calculations, Non-polymer description, Structure summary
  • Version 2.1: 2021-11-03
    Changes: Database references, Structure summary
  • Version 2.2: 2024-02-07
    Changes: Data collection
