1FYL

SERENDIPITOUS CRYSTAL STRUCTURE CONTAINING THE HEAT SHOCK TRANSCRIPTION FACTOR'S DNA BINDING DOMAIN AND COGNATE DNA IN A HEAD-TO-HEAD ORIENTATION


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free: 0.300
  • R-Value Work: 0.213

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

Crystal packing interaction that blocks crystallization of a site-specific DNA binding protein-DNA complex.

Littlefield, O.Nelson, H.C.

(2001) Proteins 45: 219-228

  • DOI: https://doi.org/10.1002/prot.1142
  • Primary Citation of Related Structures:
    1FYK, 1FYL, 1FYM

  • PubMed Abstract:

    We present here three high-resolution crystal structures of complexes between the DNA-binding domain of the heat-shock transcription factor (HSF) and DNA oligomers. Although the DNA oligomers contain HSF's specific binding sequence, called a heat-shock element, the crystal structures do not contain the specific protein-DNA complex. In one crystal structure, the 10 base pair DNA oligomer is statically disordered. In the other two related structures, the 12 base pair DNA oligomers are in unique positions, but the protein-DNA contacts in these two crystals are not sequence specific. In all three structures, the DNA appears to act as a rigid, polyanion scaffold to support columns of proteins in a crystalline lattice. A robust crystal packing interface between protein monomers obscures the true DNA-binding surface, known from previous genetic and biochemical studies. By redesigning the protein to interfere with the crystal lattice contacts, we were able to obtain physiologically relevant crystals in a specific protein-DNA complex. Thus, a crystal-packing interface was able to prevent the weak, but physiological relevant interactions between a protein and DNA.


  • Organizational Affiliation

    Department of Molecular and Cell Biology, University of California, Berkeley, California, USA.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
HEAT SHOCK FACTOR PROTEINC [auth A],
D [auth B]
92Kluyveromyces lactisMutation(s): 6
UniProt
Find proteins for P22121 (Kluyveromyces lactis (strain ATCC 8585 / CBS 2359 / DSM 70799 / NBRC 1267 / NRRL Y-1140 / WM37))
Explore P22121
Go to UniProtKB:  P22121
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP22121
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 1
MoleculeChains LengthOrganismImage
HEAD-TO-HEAD HSEA [auth C],
B [auth D]
12N/A
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
C [auth A],
D [auth B]
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free: 0.300
  • R-Value Work: 0.213
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 105.14α = 90
b = 33.73β = 118.35
c = 77.84γ = 90
Software Package:
Software NamePurpose
MLPHAREphasing
X-PLORrefinement
DENZOdata reduction
CCP4data scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2001-09-28
    Type: Initial release
  • Version 1.1: 2007-10-16
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2019-12-18
    Changes: Advisory, Data collection, Database references, Derived calculations
  • Version 1.4: 2021-11-03
    Changes: Database references, Derived calculations
