1E36

PORCINE PANCREATIC ELASTASE COMPLEXED WITH (3S, 4S)N-PARA-NITROBENZENESULPHONYL -3-ETHYL-4-(CARBOXYLIC ACID)PYRROLIDIN-2-ONE


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.7 Å
  • R-Value Free: 0.220
  • R-Value Work: 0.183

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history

Literature

'Ph-Jump' Crystallographic Analyses of Gamma-Lactam-Porcine Pancreatic Elastase Complexes

Wright, P.A.Wilmouth, R.C.Clifton, I.J.Schofield, C.J.

(2000) Biochem.J. 351: 335

  • Primary Citation of Related Structures:  1E34, 1E35, 1E37, 1E38
  • Also Cited By: 1H9L

  • PubMed Abstract:
  • beta-Lactams inhibit a range of enzymes via acylation of nucleophilic serine residues. Certain gamma-lactam analogues of monocyclic beta-lactams have also been shown to be reversible inhibitors of porcine pancreatic elastase (PPE), forming acyl-enzym ...

    beta-Lactams inhibit a range of enzymes via acylation of nucleophilic serine residues. Certain gamma-lactam analogues of monocyclic beta-lactams have also been shown to be reversible inhibitors of porcine pancreatic elastase (PPE), forming acyl-enzyme complexes that are stable with respect to hydrolysis. Crystallographic analysis at pH 5 of an acyl-enzyme complex formed with PPE and one of these inhibitors revealed the ester carbonyl located in the oxyanion hole in a similar conformation to that observed in the structure of a complex formed between a heptapeptide (beta-casomorphin-7) and PPE. Only weak electron density was observed for the His-57 side chain in its 'native' conformation. Instead, the His-57 side chain predominantly adopted a conformation rotated approx. 90 degrees from its normal position. PPE-gamma-lactam crystals were subjected to 'pH-jumps' by placing the crystals in a buffer of increased pH prior to freezing for data collection. The results indicate that the conformation of the gamma-lactam-derived acyl-enzyme species in the PPE active site is dependent on pH, a result having implications for the analysis of other serine protease-inhibitor structures at non-catalytic pH values. The results help to define the stereoelectronic relationship between the ester of the acyl-enzyme complex, the side chain of His-57 and the incoming nucleophile during the reversible (de)acylation steps, implying it is closely analogous to the hydrolytic deacylation step during catalytic peptide hydrolysis.


    Related Citations:
    • Inhibition of Elastase by N-Sulfonylaryl Beta-Lactams: Anatomy of a Stable Acyl-Enzyme Complex
      Wilmouth, R.C.,Westwood, N.J.,Anderson, K.,Brownlee, W.,Claridge, T.D.W.,Clifton, I.J.,Pritchard, G.J.,Aplin, R.T.,Schofield, C.J.
      (1998) Biochemistry 37: 17506
    • Structure of a Specific Acyl-Enzyme Complex Formed between Beta-Casomorphin-7 and Porcine Pancreatic Elastase
      Wilmouth, R.C.,Clifton, I.J.,Robinson, C.V.,Roach, P.L.,Aplin, R.T.,Westwood, N.J.,Hajdu, J.,Schofield, C.J.
      (1997) Nat.Struct.Mol.Biol. 4: 456
    • Mechanistic Insights Into the Inhibition of Serine Proteases by Monocyclic Lactams
      Wilmouth, R.C.,Kassamally, S.,Westwood, N.J.,Sheppard, R.J.,Claridge, T.D.W.,Aplin, R.T.,Wright, P.A.,Pritchard, G.J.,Schofield, C.J.
      (1999) Biochemistry 38: 7989
    • Structure of Native Porcine Pancreatic Elastase at 1.65 A Resolution
      Meyer, E.,Cole, G.,Radhakrishnan, R.,Epp, O.
      (1988) Acta Crystallogr.,Sect.B 44: 26


    Organizational Affiliation

    The Oxford Centre for Molecular Sciences and The Dyson Perrins Laboratory, South Parks Road, Oxford OX1 3QY, UK.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
ELASTASE
B
240Sus scrofaGene Names: CELA1 (ELA1)
EC: 3.4.21.36
Find proteins for P00772 (Sus scrofa)
Go to Gene View: CELA1
Go to UniProtKB:  P00772
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
TPY
Query on TPY

Download SDF File
Download CCD File
B
(2S,3S)-3-FORMYL-2-({[(4-NITROPHENYL)SULFONYL]AMINO}METHYL)PENTANOIC ACID
C13 H16 N2 O7 S
JPQYVEFTAZEPOD-BXKDBHETSA-N
 Ligand Interaction
SO4
Query on SO4

Download SDF File
Download CCD File
B
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
CA
Query on CA

Download SDF File
Download CCD File
B
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.7 Å
  • R-Value Free: 0.220
  • R-Value Work: 0.183
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 50.170α = 90.00
b = 57.560β = 90.00
c = 74.410γ = 90.00
Software Package:
Software NamePurpose
SCALEPACKdata scaling
DENZOdata reduction
REFMACrefinement
X-PLORphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2000-10-18
    Type: Initial release
  • Version 1.1: 2011-05-08
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
  • Version 1.3: 2017-07-05
    Type: Data collection
