1D4R

29-mer fragment of human srp rna helix 6


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2 Å
  • R-Value Free: 0.288
  • R-Value Work: 0.264

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

The 2 A structure of helix 6 of the human signal recognition particle RNA

Wild, K.Weichenrieder, O.Leonard, G.A.Cusack, S.

(1999) Structure Fold.Des. 7: 1345-1352


  • PubMed Abstract:
  • The mammalian signal recognition particle (SRP) is an essential cytoplasmic ribonucleoprotein complex involved in targeting signal-peptide-containing proteins to the endoplasmic reticulum. Assembly of the SRP requires protein SRP19 to bind first to h ...

    The mammalian signal recognition particle (SRP) is an essential cytoplasmic ribonucleoprotein complex involved in targeting signal-peptide-containing proteins to the endoplasmic reticulum. Assembly of the SRP requires protein SRP19 to bind first to helix 6 of the SRP RNA before the signal-peptide-recognizing protein, SRP54, can bind to helix 8 of the RNA. Helix 6 is closed by a GGAG tetraloop, which has been shown to form part of the SRP19-binding site.


    Organizational Affiliation

    EMBL Grenoble Outstation, Grenoble, F-38042, France.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsLengthOrganism
29-MER OF MODIFIED SRP RNA HELIX 6A29N/A
Entity ID: 2
MoleculeChainsLengthOrganism
29-MER OF MODIFIED SRP RNA HELIX 6B,C29N/A
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
MG
Query on MG

Download SDF File
Download CCD File
A, B, C
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
 Ligand Interaction
Modified Residues  2 Unique
IDChainsTypeFormula2D DiagramParent
A23
Query on A23
A
RNA LINKINGC10 H13 N5 O9 P2A
GDP
Query on GDP
A, B, C
RNA LINKINGC10 H15 N5 O11 P2G
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2 Å
  • R-Value Free: 0.288
  • R-Value Work: 0.264
  • Space Group: P 31 2 1
Unit Cell:
Length (Å)Angle (°)
a = 42.980α = 90.00
b = 42.980β = 90.00
c = 231.420γ = 120.00
Software Package:
Software NamePurpose
CCP4data scaling
TRUNCATEdata reduction
MOSFLMdata reduction
CNSrefinement
SOLVEphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 1999-12-02
    Type: Initial release
  • Version 1.1: 2008-04-27
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
