1COD

SOLUTION CONFORMATION OF COBROTOXIN: A NUCLEAR MAGNETIC RESONANCE AND HYBRID DISTANCE GEOMETRY-DYNAMICAL SIMULATED ANNEALING STUDY


Experimental Data Snapshot

  • Method: SOLUTION NMR
  • Conformers Submitted:

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Solution conformation of cobrotoxin: a nuclear magnetic resonance and hybrid distance geometry-dynamical simulated annealing study.

Yu, C.Bhaskaran, R.Chuang, L.C.Yang, C.C.

(1993) Biochemistry 32: 2131-2136

  • Primary Citation of Related Structures:  1COE

  • PubMed Abstract:
  • The solution conformation of cobrotoxin has been determined by using proton nuclear magnetic resonance spectroscopy. With the combination of various two-dimensional NMR techniques, the 1H-NMR spectrum of cobrotoxin was completely assigned (Yu et al., ...

    The solution conformation of cobrotoxin has been determined by using proton nuclear magnetic resonance spectroscopy. With the combination of various two-dimensional NMR techniques, the 1H-NMR spectrum of cobrotoxin was completely assigned (Yu et al., 1990). A set of 435 approximate interproton distance restraints was derived from nuclear Overhauser enhancement (NOE) measurements. These NOE constraints, in addition to the 29 dihedral angle constraints (from coupling constant measurements) and 26 hydrogen bonding restraints (from the pattern of short-range NOEs), form the basis of 3-D structure determination by the hybrid distance geometry-dynamical simulated annealing method. The 23 structures that were obtained satisfy the experimental restraints, display small deviation from idealized covalent geometry, and possess good nonbonded contacts. Analysis of converged structures indicated that there are two antiparallel beta sheets (double and triple stranded), duly confirming our earlier observations. These are well defined in terms of both atomic root mean square (RMS) differences and backbone torsional angles. The average backbone RMS deviation between the calculated structures and the mean structure, for the beta-sheet regions, is 0.92 A. The mean solution structure was compared with the X-ray crystal structure of erabutoxin b, the homologous protein. This yielded information that both structures resemble each other except at the exposed loop/surface regions, where the solution structure seems to possess more flexibility.


    Organizational Affiliation

    Chemistry Department, National Tsing Hua University, Hsinchu, Taiwan, Republic of China.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
COBROTOXIN
A
62Naja najaN/A
Find proteins for Q9PTT0 (Naja naja)
Go to UniProtKB:  Q9PTT0
Experimental Data & Validation

Experimental Data

  • Method: SOLUTION NMR
  • Conformers Submitted:
Software Package:
Software NamePurpose
X-PLORphasing
X-PLORmodel building
X-PLORrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 1995-01-26
    Type: Initial release
  • Version 1.1: 2008-03-24
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
