Experimental Data Snapshot

  • Resolution: 2.30 Å

wwPDB Validation   3D Report Full Report

This is version 1.3 of the entry. See complete history


Three-dimensional structure of adenosylcobinamide kinase/adenosylcobinamide phosphate guanylyltransferase from Salmonella typhimurium determined to 2.3 A resolution,.

Thompson, T.B.Thomas, M.G.Escalante-Semerena, J.C.Rayment, I.

(1998) Biochemistry 37: 7686-7695

  • DOI: https://doi.org/10.1021/bi973178f
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    The X-ray structure of adenosylcobinamide kinase/adenosylcobinamide phosphate guanylyltransferase (CobU) from Salmonella typhimurium has been determined to 2.3 A resolution. This enzyme of subunit molecular weight 19 770 plays a central role in the assembly of the nucleotide loop for adenosylcobalamin where it catalyzes both the phosphorylation of the 1-amino-2-propanol side chain of the corrin ring and the subsequent attachment of GMP to form the product adenosylcobinamide-GDP. The kinase activity is believed to be associated with a P-loop motif, whereas the transferase activity proceeds at a different site on the enzyme via a guanylyl intermediate. The enzyme was crystallized in the space group C2221 with unit cell dimensions of a = 96.4 A, b = 114.4 A, and c = 106.7 A, with three subunits per asymmetric unit. The structure reveals that the enzyme is a molecular trimer and appears somewhat like a propeller with overall molecular dimensions of approximately 64 A x 77 A x 131 A. Each subunit consists of a single domain that is dominated by a seven-stranded mixed beta-sheet flanked on either side by a total of five alpha-helices and one helical turn. Six of the seven beta-strands run parallel. The C-terminal strand lies at the edge of the sheet and runs antiparallel to the others. Interestingly, CobU displays a remarkable structural and topological similarity to the central domain of the RecA protein, although the reason for this observation is unclear. The structure contains a P-loop motif located at the base of a prominent cleft formed by the association of two subunits and is most likely the kinase active site. Each subunit of CobU contains a cis peptide bond between Glu80 and Cys81 where Glu80 faces the P-loop and might serve to coordinate the magnesium ion of the triphosphate substrate. Interestingly, His46, which is the putative site for guanylylation, lies approximately 21 A from the P-loop and is solvent-exposed. This suggests that the enzyme undergoes a conformational change when the substrates bind to bring these two active sites into closer proximity.

  • Organizational Affiliation

    Institute for Enzyme Research, University of Wisconsin, Madison 53705, USA.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
A, B, C
180Salmonella enterica subsp. enterica serovar TyphimuriumMutation(s): 0
Find proteins for Q05599 (Salmonella typhimurium (strain LT2 / SGSC1412 / ATCC 700720))
Explore Q05599
Go to UniProtKB:  Q05599
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ05599
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 2.30 Å
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 96.4α = 90
b = 114.4β = 90
c = 106.7γ = 90
Software Package:
Software NamePurpose
HEAVYmodel building
XDSdata reduction
XCALIBREdata scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1998-12-02
    Type: Initial release
  • Version 1.1: 2008-03-24
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2024-02-07
    Changes: Data collection, Database references, Derived calculations, Other
