1C1B

CRYSTAL STRUCTURE OF HIV-1 REVERSE TRANSCRIPTASE IN COMPLEX WITH GCA-186


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.5 Å
  • R-Value Free: 0.255
  • R-Value Work: 0.198

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history

Literature

Design of MKC-442 (emivirine) analogues with improved activity against drug-resistant HIV mutants.

Hopkins, A.L.Ren, J.Tanaka, H.Baba, M.Okamato, M.Stuart, D.I.Stammers, D.K.

(1999) J.Med.Chem. 42: 4500-4505

  • Primary Citation of Related Structures:
  • Also Cited By: 1DTT, 1DTQ

  • PubMed Abstract:
  • Two analogues of the nonnucleoside inhibitor of HIV-1 RT, MKC-442 (emivirine), containing different C6 substituents have been designed to be less susceptible to the commonly found drug-resistance mutation of Tyr181Cys. Compound TNK-6123 had a C6 thio ...

    Two analogues of the nonnucleoside inhibitor of HIV-1 RT, MKC-442 (emivirine), containing different C6 substituents have been designed to be less susceptible to the commonly found drug-resistance mutation of Tyr181Cys. Compound TNK-6123 had a C6 thiocyclohexyl group designed to have more flexibility in adapting to the mutated drug-binding site. GCA-186 had additional 3',5'-dimethyl substituents aimed at forming close contacts with the conserved residue Trp229. Both compounds showed approximately 30-fold greater inhibitory effect than MKC-442 to the Tyr181Cys mutant virus as well as to the clinically important Lys103Asn virus. X-ray crystallographic structure determination of complexes with HIV-1 RT confirmed the predicted binding modes. These strategies might be used to improve the resilience of other NNRTI series against common drug-resistance mutations.


    Related Citations:
    • Mechanism of Inhibition of HIV-1 Reverse Transcriptase by Non-nucleoside Inhibitors
      Esnouf, R.M.,Ren, J.,Ross, C.K.,Jones, E.Y.,Stammers, D.K.,Stuart, D.I.
      (1995) Nat.Struct.Mol.Biol. 2: 303
    • High Resolution Structures of HIV-1 RT From Four RT-inhibitor Complexes
      Ren, J.,Esnouf, R.M.,Garman, E.,Somers, D.O.,Ross, C.K.,Kirby, I.,Keeling, J.,Darby, G.,Jones, E.Y.,Stuart, D.I.,Stammers, D.K.
      (1995) Nat.Struct.Mol.Biol. 2: 293
    • 3'-azido-3'-deoxythymidine drug resistance mutations in HIV-1 reverse transcriptase can induce long range conformational changes
      Ren, J.,Esnouf, R.M.,Hopkins, A.L.,Jones, E.Y.,Kirby, I.,Keeling, J.,Ross, C.K.,Larder, B.A.,Stuart, D.I.,Stammers, D.K.
      (1998) Proc.Natl.Acad.Sci.USA 95: 9518
    • Crystal structures of HIV-1 reverse transcriptase in complex with carboxanilide derivatives
      Ren, J.,Esnouf, R.M.,Hopkins, A.L.,Warren, J.,Balzarini, J.,Stuart, D.I.
      (1998) Biochemistry 37: 14394
    • Continuous and discontinuous changes in the unit cell of HIV-1 reverse transcriptase crystals on dehydration
      Esnouf, R.M.,Ren, J.,Garman, E.,Somers, D.O.,Ross, C.K.,Jones, E.Y.,Stammers, D.K.,Stuart, D.I.
      (1998) Acta Crystallogr.,Sect.D 54: 938
    • The structure of HIV-1 reverse transcriptase complexed with 9-chloro-TIBO: lessons for inhibitor design
      Ren, J.,Esnouf, R.M.,Hopkins, A.L.,Ross, C.K.,Jones, E.Y.,Stammers, D.K.,Stuart, D.I.
      (1995) Structure 3: 915
    • Complexes of HIV-1 reverse transcriptase with inhibitors of the HEPT series reveal conformational changes relevant to the design of potent non-nucleoside inhibitors
      Hopkins, A.L.,Ren, J.,Esnouf, R.M.,Willcox, B.E.,Jones, E.Y.,Ross, C.K.,Miyasaka, T.,Walker, R.T.,Tanaka, H.,Stammers, D.K.,Stuart, D.I.
      (1996) J.Med.Chem. 39: 1589
    • Crystals of HIV-1 Reverse Transcriptase Diffracting to 2.2 Angstrom Resolution
      Stammers, D.K.,Somers, D.O.,Ross, C.K.,Kirby, I.,Ray, P.H.,Wilson, J.E.,Norman, M.,Ren, J.,Esnouf, R.M.,Garman, E.,Jones, E.Y.,Stuart, D.I.
      (1994) J.Mol.Biol. 242: 586
    • Crystallographic Analysis of the Binding Modes of Thiazoloisoindolinone Non-nucleoside Inhibitors to HIV-1 Reverse Transcriptase and Comparison with Modelling Studies
      Ren, J.,Esnouf, R.M.,Hopkins, A.L.,Stuart, D.I.,Stammers, D.K.
      (1999) J.Med.Chem. 42: 3845
    • Unique features in the structure of the complex between HIV-1 reverse transcriptase and the bis(heteroaryl)piperazine (BHAP) U-90152 explain resistance mutations for this non-nucleoside inhibitor
      Esnouf, R.M.,Ren, J.,Hopkins, A.L.,Ross, C.K.,Jones, E.Y.,Stammers, D.K.,Stuart, D.I.
      (1997) Proc.Natl.Acad.Sci.USA 94: 3984


    Organizational Affiliation

    Laboratory of Molecular Biophysics, Rex Richards Building, South Parks Road, Oxford OX1 3QU, U.K.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
HIV-1 REVERSE TRANSCRIPTASE (A-CHAIN)
A
560Human immunodeficiency virus type 1 group M subtype BMutation(s): 0
Gene Names: gag-pol
Find proteins for P04585 (Human immunodeficiency virus type 1 group M subtype B)
Go to UniProtKB:  P04585
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
HIV-1 REVERSE TRANSCRIPTASE (B-CHAIN)
B
440Human immunodeficiency virus type 1 group M subtype BMutation(s): 0
Gene Names: gag-pol
Find proteins for P04585 (Human immunodeficiency virus type 1 group M subtype B)
Go to UniProtKB:  P04585
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
GCA
Query on GCA

Download SDF File
Download CCD File
A
6-(3',5'-DIMETHYLBENZYL)-1-ETHOXYMETHYL-5-ISOPROPYLURACIL
GCA-186
C19 H26 N2 O3
NVGVZWUORYLPAL-UHFFFAOYSA-N
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
CSD
Query on CSD
A
L-PEPTIDE LINKINGC3 H7 N O4 SCYS
External Ligand Annotations
IDBinding Affinity (Sequence Identity %)
GCAEC50: 0.6 nM (98) BINDINGDB
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.5 Å
  • R-Value Free: 0.255
  • R-Value Work: 0.198
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 140.000α = 90.00
b = 111.500β = 90.00
c = 73.200γ = 90.00
Software Package:
Software NamePurpose
X-PLORphasing
X-PLORmodel building
CNSrefinement
DENZOdata reduction
SCALEPACKdata scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2000-07-21
    Type: Initial release
  • Version 1.1: 2008-04-27
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
  • Version 1.3: 2014-11-12
    Type: Non-polymer description
