133D

THE CRYSTAL STRUCTURE OF N4-METHYLCYTOSINE.GUANOSIN BASE-PAIRS IN THE SYNTHETIC HEXANUCLEOTIDE D(CGCGM(4)CG)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.8 Å

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

The crystal structure of N4-methylcytosine.guanosine base-pairs in the synthetic hexanucleotide d(CGCGm4CG).

Cervi, A.R.Guy, A.Leonard, G.A.Teoule, R.Hunter, W.N.

(1993) Nucleic Acids Res. 21: 5623-5629


  • PubMed Abstract:
  • The structure of d(CGCGm4CG) were m4C = N4-methylcytosine has been determined by crystallographic methods. The crystals are multifaced prisms, with orthorhombic space group P2(1)2(1)2(1) and unit cell dimensions of a = 17.98, b = 30.77 and c = 44.75A ...

    The structure of d(CGCGm4CG) were m4C = N4-methylcytosine has been determined by crystallographic methods. The crystals are multifaced prisms, with orthorhombic space group P2(1)2(1)2(1) and unit cell dimensions of a = 17.98, b = 30.77 and c = 44.75A. The asymmetric unit consists of one duplex of hexanucleotide and 49 waters. The R-factor is 0.189 for 1495 reflections with F > or = sigma(F) to a resolution limit of 1.8A. The double helix has a Z-DNA type structure which appears to be intermediate in structure to the two previously characterised structure types for Z-DNA hexamers. The two m4C.G base-pairs adopt structures that are very similar to those of the equivalent base-pairs in the structure of the native sequence d(CGCGCG) except for the presence of the methyl groups which are trans to the N3 atoms of their parent nucleotides and protrude into the solvent region. The introduction of the modified base-pairs into the d(CGCGCG) duplex appears to have a minimal effect on the overall base-pair morphology of the Z-DNA duplex.


    Organizational Affiliation

    Department of Chemistry, University of Manchester, UK.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsLengthOrganism
DNA (5'-D(*CP*GP*CP*GP*(C34)P*G)-3')A,B6N/A
Small Molecules
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
C34
Query on C34
A, B
DNA LINKINGC10 H16 N3 O7 PDC
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.8 Å
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 17.980α = 90.00
b = 30.770β = 90.00
c = 44.760γ = 90.00
Software Package:
Software NamePurpose
NUCLSQrefinement
X-PLORrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 1994-01-15
    Type: Initial release
  • Version 1.1: 2008-05-22
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
