8QYP

Beta-cardiac myosin motor domain in the pre-powerstroke state


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.76 Å
  • R-Value Free: 0.248
  • R-Value Work: 0.190
  • R-Value Observed: 0.193

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history

Re-refinement Note

This entry reflects an alternative modeling of the original data in: 5N6A


Literature

Omecamtiv mecarbil and Mavacamten target the same myosin pocket despite antagonistic effects in heart contraction.

Auguin, D.Robert-Paganin, J.Rety, S.Kikuti, C.David, A.Theumer, G.Schmidt, A.W.Knolker, H.J.Houdusse, A.

(2023) Biorxiv

  • DOI: https://doi.org/10.1101/2023.11.15.567213
  • Primary Citation of Related Structures:
    8QYP, 8QYQ, 8QYR, 8QYU

  • PubMed Abstract:

    Inherited cardiomyopathies are amongst the most common cardiac diseases worldwide, leading in the late-stage to heart failure and death. The most promising treatments against these diseases are small-molecules directly modulating the force produced by β-cardiac myosin, the molecular motor driving heart contraction. Two of these molecules that produce antagonistic effects on cardiac contractility have completed clinical phase 3 trials: the activator Omecamtiv mecarbil and the inhibitor Mavacamten . In this work, we reveal by X-ray crystallography that both drugs target the same pocket and stabilize a pre-stroke structural state, with only few local differences. All atoms molecular dynamics simulations reveal how these molecules can have antagonistic impact on the allostery of the motor by comparing β-cardiac myosin in the apo form or bound to Omecamtiv mecarbil or Mavacamten . Altogether, our results provide the framework for rational drug development for the purpose of personalized medicine.


  • Organizational Affiliation

    Structural Motility, UMR 144 CNRS/Curie Institute, PSL Research University, 26 rue d'Ulm, 75258 Paris cedex 05, France.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Myosin-7780Bos taurusMutation(s): 0
UniProt
Find proteins for Q9BE39 (Bos taurus)
Explore Q9BE39
Go to UniProtKB:  Q9BE39
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9BE39
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
M3L
Query on M3L
A
L-PEPTIDE LINKINGC9 H21 N2 O2LYS
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.76 Å
  • R-Value Free: 0.248
  • R-Value Work: 0.190
  • R-Value Observed: 0.193
  • Space Group: P 43 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 94.397α = 90
b = 94.397β = 90
c = 219.693γ = 90
Software Package:
Software NamePurpose
BUSTERrefinement
autoPROCdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
The French Muscular Dystrophy Telethon (AFM-Telethon)France21805
Fondation pour la Recherche Medicale (FRM)FranceDCM20181039553
Agence Nationale de la Recherche (ANR)France21-CE11-0022-01
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesRM1GM131981-01

Revision History  (Full details and data files)

  • Version 1.0: 2023-12-13
    Type: Initial release
