8B48

Structure of Lentithecium fluviatile carbohydrate esterase from the CE15 family (LfCE15C)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.65 Å
  • R-Value Free: 0.298
  • R-Value Work: 0.238

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Structural and functional investigation of a fungal member of carbohydrate esterase family 15 with potential specificity for rare xylans.

Mazurkewich, S.Scholzen, K.C.Brusch, R.H.Poulsen, J.C.N.Theibich, Y.Huttner, S.Olsson, L.Larsbrink, J.Lo Leggio, L.

(2023) Acta Crystallogr D Struct Biol 79: 545-555

  • DOI: https://doi.org/10.1107/S205979832300325X
  • Primary Citation of Related Structures:
    8B48

  • PubMed Abstract:

    In plant cell walls, covalent bonds between polysaccharides and lignin increase recalcitrance to degradation. Ester bonds are known to exist between glucuronic acid moieties on glucuronoxylan and lignin, and these can be cleaved by glucuronoyl esterases (GEs) from carbohydrate esterase family 15 (CE15). GEs are found in both bacteria and fungi, and some microorganisms also encode multiple GEs, although the reason for this is still not fully clear. The fungus Lentithecium fluviatile encodes three CE15 enzymes, of which two have previously been heterologously produced, although neither was active on the tested model substrate. Here, one of these, LfCE15C, has been investigated in detail using a range of model and natural substrates and its structure has been solved using X-ray crystallography. No activity could be verified on any tested substrate, but biophysical assays indicate an ability to bind to complex carbohydrate ligands. The structure further suggests that this enzyme, which possesses an intact catalytic triad, might be able to bind and act on more extensively decorated xylan chains than has been reported for other CE15 members. It is speculated that rare glucuronoxylans decorated at the glucuronic acid moiety may be the true targets of LfCE15C and other CE15 family members with similar sequence characteristics.


  • Organizational Affiliation

    Wallenberg Wood Science Center, Division of Industrial Biotechnology, Department of Life Sciences, Chalmers University of Technology, 412 96 Gothenburg, Sweden.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Carbohydrate esterase family 15 protein
A, B, C, D
394Lentithecium fluviatileMutation(s): 0
Gene Names: K458DRAFT_349146
UniProt
Find proteins for A0A6G1IIU9 (Lentithecium fluviatile CBS 122367)
Explore A0A6G1IIU9
Go to UniProtKB:  A0A6G1IIU9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A6G1IIU9
Sequence Annotations
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 2
MoleculeChains Length2D Diagram Glycosylation3D Interactions
alpha-D-mannopyranose-(1-3)-beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
E
4N-Glycosylation
Glycosylation Resources
GlyTouCan:  G81315DD
GlyCosmos:  G81315DD
GlyGen:  G81315DD
Entity ID: 3
MoleculeChains Length2D Diagram Glycosylation3D Interactions
alpha-D-mannopyranose-(1-3)-[alpha-D-mannopyranose-(1-6)]beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
F, H
5N-Glycosylation
Glycosylation Resources
GlyTouCan:  G22768VO
GlyCosmos:  G22768VO
GlyGen:  G22768VO
Entity ID: 4
MoleculeChains Length2D Diagram Glycosylation3D Interactions
alpha-D-mannopyranose-(1-3)-alpha-D-mannopyranose-(1-6)-[alpha-D-mannopyranose-(1-3)]beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
G
6N-Glycosylation
Glycosylation Resources
GlyTouCan:  G09724ZC
GlyCosmos:  G09724ZC
GlyGen:  G09724ZC
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.65 Å
  • R-Value Free: 0.298
  • R-Value Work: 0.238
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 70.74α = 113.322
b = 79.57β = 98.531
c = 86.01γ = 94.44
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
XSCALEdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Novo Nordisk FoundationDenmarkNNF17OC0027698
Novo Nordisk FoundationDenmarkNNF21OC0071611

Revision History  (Full details and data files)

  • Version 1.0: 2023-06-07
    Type: Initial release
  • Version 1.1: 2024-02-07
    Changes: Data collection, Refinement description
