5K3O

Wolinella succinogenes L-asparaginase P121 and L-Aspartic acid


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.696 Å
  • R-Value Free: 0.207
  • R-Value Work: 0.175

wwPDB Validation 3D Report Full Report


This is version 1.0 of the entry. See complete history

Literature

The differential ability of asparagine and glutamine in promoting the closed/active enzyme conformation rationalizes the Wolinella succinogenes L-asparaginase substrate specificity.

Nguyen, H.A.Durden, D.L.Lavie, A.

(2017) Sci Rep 7: 41643-41643

  • DOI: 10.1038/srep41643
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Many side effects of current FDA-approved L-asparaginases have been related to their secondary L-glutaminase activity. The Wolinella succinogenes L-asparaginase (WoA) has been reported to be L-glutaminase free, suggesting it would have fewer side eff ...

    Many side effects of current FDA-approved L-asparaginases have been related to their secondary L-glutaminase activity. The Wolinella succinogenes L-asparaginase (WoA) has been reported to be L-glutaminase free, suggesting it would have fewer side effects. Unexpectedly, the WoA variant with a proline at position 121 (WoA-P121) was found to have L-glutaminase activity in contrast to Uniprot entry P50286 (WoA-S121) that has a serine residue at this position. Towards understanding how this residue impacts the L-glutaminase property, kinetic analysis was coupled with crystal structure determination of these WoA variants. WoA-S121 was confirmed to have much lower L-glutaminase activity than WoA-P121, yet both showed comparable L-asparaginase activity. Structures of the WoA variants in complex with L-aspartic acid versus L-glutamic acid provide insights into their differential substrate selectivity. Structural analysis suggests a mechanism by which residue 121 impacts the conformation of the conserved tyrosine 27, a component of the catalytically-important flexible N-terminal loop. Surprisingly, we could fully model this loop in either its open or closed conformations, revealing the roles of specific residues of an evolutionary conserved motif among this L-asparaginase family. Together, this work showcases critical residues that influence the ability of the flexible N-terminal loop for adopting its active conformation, thereby effecting substrate specificity.


    Organizational Affiliation

    The Jesse Brown VA Medical Center, Chicago, Illinois, United States of America.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
L-asparaginase
A, B, C, D
330Wolinella succinogenes (strain ATCC 29543 / DSM 1740 / LMG 7466 / NCTC 11488 / FDC 602W)Mutation(s): 1
Gene Names: ansA (ansB)
EC: 3.5.1.1
Find proteins for P50286 (Wolinella succinogenes (strain ATCC 29543 / DSM 1740 / LMG 7466 / NCTC 11488 / FDC 602W))
Go to UniProtKB:  P50286
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ASP
Query on ASP

Download SDF File
Download CCD File
A, B, C, D
ASPARTIC ACID
C4 H7 N O4
CKLJMWTZIZZHCS-REOHCLBHSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.696 Å
  • R-Value Free: 0.207
  • R-Value Work: 0.175
  • Space Group: C 1 2 1
Unit Cell:
Length (Å)Angle (°)
a = 144.755α = 90.00
b = 71.459β = 118.07
c = 141.502γ = 90.00
Software Package:
Software NamePurpose
XDSdata scaling
MOLREPphasing
REFMACrefinement
XDSdata reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

  • Deposited Date: 2016-05-19
  • Released Date: 2017-03-29
  • Deposition Author(s): Nguyen, H.A., Lave, A.

Revision History

  • Version 1.0: 2017-03-29
    Type: Initial release
