4ZO0

X-ray Structure of AAV-2 Origin Binding Domain

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.242
  • R-Value Work: 0.225
  • R-Value Observed: 0.226

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history.


Literature

Structural Studies of AAV2 Rep68 Reveal a Partially Structured Linker and Compact Domain Conformation.

Musayev, F.N., Zarate-Perez, F., Bardelli, M., Bishop, C., Saniev, E.F., Linden, R.M., Henckaerts, E., Escalante, C.R.

(2015) Biochemistry 54: 5907-5919

  • DOI: 10.1021/acs.biochem.5b00610
  • Primary Citation of Related Structures:
    4ZO0, 5DCX

  • PubMed Abstract:

    • Adeno-associated virus (AAV) nonstructural proteins Rep78 and Rep68 carry out all DNA transactions that regulate the AAV life cycle. They share two multifunctional domains: an N-terminal origin binding/nicking domain (OBD) from the HUH superfamily and a SF3 helicase domain ...

    Adeno-associated virus (AAV) nonstructural proteins Rep78 and Rep68 carry out all DNA transactions that regulate the AAV life cycle. They share two multifunctional domains: an N-terminal origin binding/nicking domain (OBD) from the HUH superfamily and a SF3 helicase domain. A short linker of ∼20 amino acids that is critical for oligomerization and function connects the two domains. Although X-ray structures of the AAV5 OBD and AAV2 helicase domains have been determined, information about the full-length protein and linker conformation is not known. This article presents the solution structure of AAV2 Rep68 using small-angle X-ray scattering (SAXS). We first determined the X-ray structures of the minimal AAV2 Rep68 OBD and of the OBD with the linker region. These X-ray structures reveal novel features that include a long C-terminal α-helix that protrudes from the core of the protein at a 45° angle and a partially structured linker. SAXS studies corroborate that the linker is not extended, and we show that a proline residue in the linker is critical for Rep68 oligomerization and function. SAXS-based rigid-body modeling of Rep68 confirms these observations, showing a compact arrangement of the two domains in which they acquire a conformation that positions key residues in all domains on one face of the protein, poised to interact with DNA.

    Organizational Affiliation:

    Department of Infectious Diseases, King's College London , London SE1 9RT, United Kingdom.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Protein Rep68 A, B, C209Adeno-associated virus 2 Srivastava/1982Mutation(s): 2
Gene Names: Rep68
EC: 3.6.4.12
Find proteins for P03132 (Adeno-associated virus 2 (isolate Srivastava/1982))
Explore P03132
Go to UniProtKB:  P03132
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
IPA
Query on IPA
Download Ideal Coordinates CCD File
A
ISOPROPYL ALCOHOL
C3 H8 O
KFZMGEQAYNKOFK-UHFFFAOYSA-N		 Ligand Interaction
MG
Query on MG
Download Ideal Coordinates CCD File
A, B, C
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N		 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.242
  • R-Value Work: 0.225
  • R-Value Observed: 0.226
  • Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 186.36α = 90
b = 154.4β = 90
c = 38.78γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
PDB_EXTRACTdata extraction
HKL-2000data reduction
HKL-2000data scaling
PHENIXphasing

Structure Validation

View Full Validation Report


View more in-depth experimental data

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR01-GM092854

Revision History  (Full details and data files)

  • Version 1.0: 2015-10-07
    Type: Initial release
  • Version 1.1: 2017-08-09
    Changes: Database references, Derived calculations
  • Version 1.2: 2017-09-27
    Changes: Author supporting evidence
  • Version 1.3: 2019-12-25
    Changes: Author supporting evidence
