3EF7

ZP-N domain of mammalian sperm receptor ZP3 (crystal form III)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.10 Å
  • R-Value Free: 0.256
  • R-Value Work: 0.208
  • R-Value Observed: 0.210

wwPDB Validation   3D Report Full Report



Literature

Crystal structure of the ZP-N domain of ZP3 reveals the core fold of animal egg coats

Monne, M.Han, L.Schwend, T.Burendahl, S.Jovine, L.

(2008) Nature 456: 653-657

  • DOI: 10.1038/nature07599
  • Primary Citation of Related Structures:
    3EF7, 3D4C, 3D4G, 5OSQ

  • PubMed Abstract:
  • Species-specific recognition between the egg extracellular matrix (zona pellucida) and sperm is the first, crucial step of mammalian fertilization. Zona pellucida filament components ZP3 and ZP2 act as sperm receptors, and mice lacking either of the ...

    Species-specific recognition between the egg extracellular matrix (zona pellucida) and sperm is the first, crucial step of mammalian fertilization. Zona pellucida filament components ZP3 and ZP2 act as sperm receptors, and mice lacking either of the corresponding genes produce oocytes without a zona pellucida and are completely infertile. Like their counterparts in the vitelline envelope of non-mammalian eggs and many other secreted eukaryotic proteins, zona pellucida subunits polymerize using a 'zona pellucida (ZP) domain' module, whose conserved amino-terminal part (ZP-N) was suggested to constitute a domain of its own. No atomic structure has been reported for ZP domain proteins, and there is no structural information on any conserved vertebrate protein that is essential for fertilization and directly involved in egg-sperm binding. Here we describe the 2.3 ångström (A) resolution structure of the ZP-N fragment of mouse primary sperm receptor ZP3. The ZP-N fold defines a new immunoglobulin superfamily subtype with a beta-sheet extension characterized by an E' strand and an invariant tyrosine residue implicated in polymerization. The structure strongly supports the presence of ZP-N repeats within the N-terminal region of ZP2 and other vertebrate zona pellucida/vitelline envelope proteins, with implications for overall egg coat architecture, the post-fertilization block to polyspermy and speciation. Moreover, it provides an important framework for understanding human diseases caused by mutations in ZP domain proteins and developing new methods of non-hormonal contraception.


    Related Citations:
    • Mammalian sperm-egg interaction: identification of a glycoprotein in mouse egg zonae pellucidae possessing receptor activity for sperm
      Bleil, J.D., Wassarman, P.M.
      (1980) Cell 20: 873
    • A large domain common to sperm receptors (Zp2 and Zp3) and TGF-beta type III receptor
      Bork, P., Sander, C.
      (1992) FEBS Lett 300: 237
    • The ZP domain is a conserved module for polymerization of extracellular proteins
      Jovine, L., Qi, H., Williams, Z., Litscher, E., Wassarman, P.M.
      (2002) Nat Cell Biol 4: 457
    • A duplicated motif controls assembly of zona pellucida domain proteins
      Jovine, L., Qi, H., Williams, Z., Litscher, E.S., Wassarman, P.M.
      (2004) Proc Natl Acad Sci U S A 101: 5922
    • Zona pellucida domain proteins
      Jovine, L., Darie, C.C., Litscher, E.S., Wassarman, P.M.
      (2005) Annu Rev Biochem 74: 83
    • The PLAC1-homology region of the ZP domain is sufficient for protein polymerisation
      Jovine, L., Janssen, W.G., Litscher, E.S., Wassarman, P.M.
      (2006) BMC Biochem 7: 11

    Organizational Affiliation

    Karolinska Institutet, Department of Biosciences and Nutrition, Hälsovägen 7, SE-141 57 Huddinge, Sweden.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Maltose-binding periplasmic protein, LINKER, Zona pellucida protein 3AB481Escherichia coli K-12Mus musculus
This entity is chimeric
Mutation(s): 5
Gene Names: Zp3Zp-3Zpc
Find proteins for P0AEX9 (Escherichia coli (strain K12))
Explore P0AEX9
Go to UniProtKB:  P0AEX9
Find proteins for P10761 (Mus musculus)
Explore P10761
Go to UniProtKB:  P10761
Protein Feature View
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 2
MoleculeChainsChain Length2D Diagram Glycosylation3D Interactions
alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose
C, D
2 N/A Oligosaccharides Interaction
Biologically Interesting Molecules (External Reference) 1 Unique
Entity ID: 2
IDChainsNameType/Class2D Diagram3D Interactions
PRD_900001
Query on PRD_900001
C, Dalpha-maltoseOligosaccharide /  Nutrient

--

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.10 Å
  • R-Value Free: 0.256
  • R-Value Work: 0.208
  • R-Value Observed: 0.210
  • Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 86.2α = 90
b = 98.58β = 90
c = 143.68γ = 90
Software Package:
Software NamePurpose
MxCuBEdata collection
PHASERphasing
PHENIXrefinement
XDSdata reduction
XDSdata scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

  • Deposited Date: 2008-09-08
  • Released Date: 2008-12-02
  • Deposition Author(s): Monne, M., Jovine, L.

Revision History

  • Version 1.0: 2008-12-02
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Derived calculations, Version format compliance
  • Version 1.2: 2017-06-28
    Changes: Source and taxonomy
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Atomic model, Data collection, Database references, Derived calculations, Non-polymer description, Structure summary
