1KDT

CYTIDINE MONOPHOSPHATE KINASE FROM E.COLI IN COMPLEX WITH 2',3'-DIDEOXY-CYTIDINE MONOPHOSPHATE


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.95 Å
  • R-Value Free: 0.253
  • R-Value Work: 0.221

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Sugar specificity of bacterial CMP kinases as revealed by crystal structures and mutagenesis of Escherichia coli enzyme.

Bertrand, T.Briozzo, P.Assairi, L.Ofiteru, A.Bucurenci, N.Munier-Lehmann, H.Golinelli-Pimpaneau, B.Barzu, O.Gilles, A.M.

(2002) J.Mol.Biol. 315: 1099-1110

  • DOI: 10.1006/jmbi.2001.5286
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Bacterial cytidine monophosphate (CMP) kinases are characterised by an insert enlarging their CMP binding domain, and by their particular substrate specificity. Thus, both CMP and 2'-deoxy-CMP (dCMP) are good phosphate acceptors for the CMP kinase fr ...

    Bacterial cytidine monophosphate (CMP) kinases are characterised by an insert enlarging their CMP binding domain, and by their particular substrate specificity. Thus, both CMP and 2'-deoxy-CMP (dCMP) are good phosphate acceptors for the CMP kinase from Escherichia coli (E. coli CMPK), whereas eukaryotic UMP/CMP kinases phosphorylate the deoxynucleotides with very low efficiency. Four crystal structures of E. coli CMPK complexed with nucleoside monophosphates differing in their sugar moiety were solved. Both structures with CMP or dCMP show interactions with the pentose that were not described so far. These interactions are lost with the poorer substrates AraCMP and 2',3'-dideoxy-CMP. Comparison of all four structures shows that the pentose hydroxyls are involved in ligand-induced movements of enzyme domains. It also gives a structural basis of the mechanism by which either ribose or deoxyribose can be accommodated. In parallel, for the four nucleotides the kinetic results of the wild-type enzyme and of three structure-based variants are presented. The phosphorylation rate is significantly decreased when either of the two pentose interacting residues is mutated. One of these is an arginine that is highly conserved in all known nucleoside monophosphate kinases. In contrast, the other residue, Asp185, is typical of bacterial CMP kinases. It interacts with Ser101, the only residue conserved in all CMP binding domain inserts. Mutating Ser101 reduces CMP phosphorylation only moderately, but dramatically reduces dCMP phosphorylation. This is the first experimental evidence of a catalytic role involving the characteristic insert of bacterial CMP kinases. Furthermore, this role concerns only dCMP phosphorylation, a feature of this family of enzymes.


    Organizational Affiliation

    Laboratoire d'Enzymologie et de Biochimie Structurales, UPR 9063 du CNRS, Gif-sur-Yvette Cedex, 91198, France.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
CYTIDYLATE KINASE
A, B
227Escherichia coli (strain K12)Mutation(s): 0
Gene Names: cmk (mssA, ycaF, ycaG)
EC: 2.7.4.25
Find proteins for P0A6I0 (Escherichia coli (strain K12))
Go to UniProtKB:  P0A6I0
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download SDF File
Download CCD File
A, B
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
DOC
Query on DOC

Download SDF File
Download CCD File
A, B
2',3'-DIDEOXYCYTIDINE-5'-MONOPHOSPHATE
C9 H14 N3 O6 P
RAJMXAZJKUGYGW-POYBYMJQSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.95 Å
  • R-Value Free: 0.253
  • R-Value Work: 0.221
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 72.648α = 90.00
b = 75.313β = 90.00
c = 78.037γ = 90.00
Software Package:
Software NamePurpose
AMoREphasing
DENZOdata reduction
CNSrefinement
SCALEPACKdata scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2002-01-22
    Type: Initial release
  • Version 1.1: 2008-04-27
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
