1JL6

Crystal Structure of CN-Ligated Component IV Glycera Dibranchiata Monomeric Hemoglobin


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.4 Å
  • R-Value Free: 0.216
  • R-Value Work: 0.179

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Crystal Structures of Unligated and CN-Ligated Glycera dibranchiata Monomer Ferric Hemoglobin Components III and IV

Park, H.J.Yang, C.Treff, N.Satterlee, J.D.Kang, C.

(2002) Proteins 49: 49-60

  • DOI: 10.1002/prot.10199
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Erythrocytes of the marine annelid, Glycera dibranchiata, contain a mixture of monomeric and polymeric hemoglobins. There are three major monomer hemoglobin components, II, III, IV (also called GMH2, 3, and 4), that have been highly purified and well ...

    Erythrocytes of the marine annelid, Glycera dibranchiata, contain a mixture of monomeric and polymeric hemoglobins. There are three major monomer hemoglobin components, II, III, IV (also called GMH2, 3, and 4), that have been highly purified and well characterized. We have now crystallized GMH3 and GMH4 and determined their structures to 1.4-1.8 A resolution. The structures were determined for these two monomer hemoglobins in the oxidized (Fe3+, ferric, or met-) forms in both the unligated and cyanide-ligated states. This work differs from two published, refined structures of a Glycera dibranchiata monomer hemoglobin, which has a sequence that is substantially different from any bona fide major monomer hemoglobins (GMH2, 3, or 4). The high-resolution crystal structures (presented here) and the previous NMR structure of CO-ligated GMH4, provide a basis for interpreting structure/function details of the monomer hemoglobins. These details include: (1) the strong correlation between temperature factor and NMR dynamics for respective protein forms; (2) the unique nature of the HisE7Leu primary sequence substitutions in GMH3 and GMH4 and their impact on cyanide ion binding kinetics; (3) the LeuB10Phe difference between GMH3 and GMH4 and its impact on ligand binding; and (4) elucidation of changes in the structural details of the distal and proximal heme pockets upon cyanide binding.


    Organizational Affiliation

    School of Molecular Biosciences, Washington State University, Pullman, Washington 99164-4660, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
monomer hemoglobin component IV
A
147Glycera dibranchiata
Find proteins for P15447 (Glycera dibranchiata)
Go to UniProtKB:  P15447
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
CYN
Query on CYN

Download SDF File
Download CCD File
A
CYANIDE ION
C N
XFXPMWWXUTWYJX-UHFFFAOYSA-N
 Ligand Interaction
HEM
Query on HEM

Download SDF File
Download CCD File
A
PROTOPORPHYRIN IX CONTAINING FE
HEME
C34 H32 Fe N4 O4
KABFMIBPWCXCRK-RGGAHWMASA-L
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.4 Å
  • R-Value Free: 0.216
  • R-Value Work: 0.179
  • Space Group: P 1 21 1
Unit Cell:
Length (Å)Angle (°)
a = 61.011α = 90.00
b = 32.890β = 109.07
c = 40.710γ = 90.00
Software Package:
Software NamePurpose
X-PLORphasing
SCALEPACKdata scaling
X-PLORrefinement
X-PLORmodel building
DENZOdata reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2002-07-16
    Type: Initial release
  • Version 1.1: 2008-04-27
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
