9ZNH | pdb_00009znh

Crystal Structure of 6,7-dimethyl-8-ribityllumazine synthase from Bordetella pertussis

PDB DOI: https://doi.org/10.2210/pdb9ZNH/pdb

Classification: TRANSFERASE
Organism(s): Bordetella pertussis Tohama I
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2025-12-12 Released: 2025-12-24
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID), National Institutes of Health/Office of the Director

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.34 Å
R-Value Free:
0.259 (Depositor), 0.257 (DCC)
R-Value Work:
0.214 (Depositor), 0.217 (DCC)
R-Value Observed:
0.217 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Crystal Structure of 6,7-dimethyl-8-ribityllumazine synthase from Bordetella pertussis

Seibold, S., Liu, L., Lovell, S., Battaile, K.P.

To be published.

Macromolecule Content

Total Structure Weight: 87.91 kDa
Atom Count: 5,502
Modeled Residue Count: 760
Deposited Residue Count: 815
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
6,7-dimethyl-8-ribityllumazine synthase	A, B, C, D, E	163	Bordetella pertussis Tohama I	Mutation(s): 0 Gene Names: ribH, BP3485 EC: 2.5.1.78
UniProt
Find proteins for Q7VTN4 (Bordetella pertussis (strain Tohama I / ATCC BAA-589 / NCTC 13251)) Explore Q7VTN4 Go to UniProtKB: Q7VTN4
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q7VTN4
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PG4 Query on PG4 Download Ideal Coordinates CCD File SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain L [auth B] SDF format, chain P [auth E] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain L [auth B] MOL2 format, chain P [auth E] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain L [auth B] mmCIF format, chain P [auth E]	H [auth A], I [auth A], L [auth B], P [auth E]	TETRAETHYLENE GLYCOL C₈ H₁₈ O₅ UWHCKJMYHZGTIT-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Focus chain I [auth A] Focus chain L [auth B] Focus chain P [auth E] Interactions & Density Focus chain H [auth A] Focus chain I [auth A] Focus chain L [auth B] Focus chain P [auth E]
BCN Query on BCN Download Ideal Coordinates CCD File SDF format, chain Q [auth E] SDF format, chain N [auth C] MOL2 format, chain Q [auth E] MOL2 format, chain N [auth C] mmCIF format, chain Q [auth E] mmCIF format, chain N [auth C]	N [auth C], Q [auth E]	BICINE C₆ H₁₃ N O₄ FSVCELGFZIQNCK-UHFFFAOYSA-N		Interactions Focus chain N [auth C] Focus chain Q [auth E] Interactions & Density Focus chain N [auth C] Focus chain Q [auth E]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain J [auth B] SDF format, chain K [auth B] SDF format, chain M [auth C] SDF format, chain O [auth E] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain J [auth B] MOL2 format, chain K [auth B] MOL2 format, chain M [auth C] MOL2 format, chain O [auth E] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain J [auth B] mmCIF format, chain K [auth B] mmCIF format, chain M [auth C] mmCIF format, chain O [auth E]	F [auth A] G [auth A] J [auth B] K [auth B] M [auth C] F [auth A], G [auth A], J [auth B], K [auth B], M [auth C], O [auth E]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain F [auth A] Focus chain G [auth A] Focus chain J [auth B] Focus chain K [auth B] Focus chain M [auth C] Focus chain O [auth E] Interactions & Density Focus chain F [auth A] Focus chain G [auth A] Focus chain J [auth B] Focus chain K [auth B] Focus chain M [auth C] Focus chain O [auth E]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.34 Å
R-Value Free: 0.259 (Depositor), 0.257 (DCC)
R-Value Work: 0.214 (Depositor), 0.217 (DCC)
R-Value Observed: 0.217 (Depositor)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 133.82	α = 90
b = 75.05	β = 113.27
c = 92.46	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XSCALE	data scaling
XDS	data reduction
PHASER	phasing
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History & Funding Information

Deposition Data

Released Date: 2025-12-24

Deposition Author(s):

Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	75N93022C00036
National Institutes of Health/Office of the Director	United States	S10OD030394
