9UFQ | pdb_00009ufq

Crystal structure of L-asparaginase from Thermococcus Sibiricus


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free:
    0.214 (Depositor), 0.222 (DCC)
  • R-Value Work:
    0.167 (Depositor), 0.176 (DCC)
  • R-Value Observed:
    0.169 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Hyperthermophilic L-Asparaginase from Thermococcus sibiricus and Its Double Mutant with Increased Activity: Insights into Substrate Specificity and Structure.

Dumina, M.V.Zhdanov, D.D.Veselovsky, A.V.Pokrovskaya, M.V.Aleksandrova, S.S.Minyaev, M.E.Varfolomeeva, L.A.Matyuta, I.O.Boyko, K.M.Zhgun, A.A.

(2025) Int J Mol Sci 26

  • DOI: https://doi.org/10.3390/ijms26125437
  • Primary Citation of Related Structures:
    9UFQ, 9UFR

  • PubMed Abstract:

    L-asparaginase (L-ASNase) is a key industrial enzyme significant for cancer therapy and the food industry for reducing dietary acrylamide. The hyperthermophilic L-ASNase from Thermococcus sibiricus (TsAI) was previously shown to exhibit high activity and thermostability and is promising for biotechnology. To gain insights into structure-functional relationships of TsAI, determination of the substrate specificity, kinetic parameters, structural characterization, and molecular docking were performed. TsAI characteristics were compared with the TsAI D54G/T56Q mutant, which exhibited increased activity after a double mutation in the substrate-binding region. TsAI and TsAI D54G/T56Q were found to display high activity towards D-asparagine-62% and 21% of L-asparaginase activity, respectively-and low L-glutaminase coactivity of ~5%. Restoring the mesophilic-like triad GSQ in the mutant resulted in a two-fold increase in activity towards L-asparagine compared with TsAI. Crystal structures of TsAI forms solved at 1.9 Å resolution revealed that double mesophilic-like mutation increased the flexibility of the loop M51-L57, located in close proximity to the active site. Structural superposition and mutational analysis indicate that mobility of this loop is essential for the activity of thermo-ASNases. Molecular docking, without taking into account the temperature factor, showed that, in contrast to L-asparagine interaction, D-asparagine orientation in the TsAI and TsAI D54G/T56Q active sites is similar and not optimal for catalysis. Under real conditions, high temperatures can induce structural changes that reduce L-ASNase discrimination towards D-asparagine. Overall, the obtained structural and biochemical data provide a basis for a more detailed understanding of thermo-ASNase functioning and possibilities to engineer improved variants for future biotechnological application.


  • Organizational Affiliation
    • Federal Research Center "Fundamentals of Biotechnology" of the Russian Academy of Sciences, Moscow 117312, Russia.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
asparaginase331Thermococcus sibiricusMutation(s): 0
Gene Names: XD54_1198
EC: 3.5.1.1
UniProt
Find proteins for C6A532 (Thermococcus sibiricus (strain DSM 12597 / MM 739))
Explore C6A532
Go to UniProtKB:  C6A532
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC6A532
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free:  0.214 (Depositor), 0.222 (DCC)
  • R-Value Work:  0.167 (Depositor), 0.176 (DCC)
  • R-Value Observed: 0.169 (Depositor)
Space Group: P 2 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 45.193α = 90
b = 57.791β = 90
c = 131.158γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
Aimlessdata scaling
PDB_EXTRACTdata extraction
CrysalisProdata reduction
MOLREPphasing
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2025-06-11
    Type: Initial release
  • Version 1.1: 2025-06-18
    Changes: Database references
  • Version 1.2: 2025-06-25
    Changes: Database references
  • Version 1.3: 2025-07-09
    Changes: Database references
