9RXW | pdb_00009rxw

Ty1 Prime Retrotransposon Capsid C-Terminal Domain, wt


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free:
    0.202 (Depositor), 0.193 (DCC)
  • R-Value Work:
    0.180 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Probing the molecular determinants of Ty1 retrotransposon restriction specificity in yeast.

Beckwith, S.L.Cottee, M.A.Hannon-Hatfield, J.A.Newman, A.C.Walker, E.C.Romero, J.R.Stoye, J.P.Taylor, I.A.Garfinkel, D.J.

(2025) PLoS Genet 21: e1011898-e1011898

  • DOI: https://doi.org/10.1371/journal.pgen.1011898
  • Primary Citation of Related Structures:
    9RXW, 9RXX, 9RXY

  • PubMed Abstract:

    The evolutionary history of retrotransposons and their hosts shapes the dynamics of transposition and restriction. The Pseudoviridae of yeast includes multiple Ty1 LTR-retrotransposon subfamilies. Saccharomyces cerevisiae prevents uncontrolled retrotransposition of Ty1 subfamilies using distinct mechanisms: canonical Ty1 is inhibited by a self-encoded restriction factor, p22/p18, whereas Ty1' is inhibited by an endogenized restriction factor, Drt2. The minimal inhibitory fragment of both restriction factors (p18m and Drt2m) is a conserved C-terminal capsid domain. Here, we use biophysical and genetic approaches to demonstrate that p18m and Drt2m are highly specific to their subfamilies. Although the crystal structures of p18m and Drt2m are similar, three divergent residues found in a conserved hydrophobic interface direct restriction specificity. By mutating these three residues, we re-target each restriction factor to the opposite transposon. Our work highlights how a common lattice-poisoning mechanism of restriction evolved from independent evolutionary trajectories in closely related retrotransposon subfamilies. These data raise the possibility that similar capsid-capsid interactions may exist in other transposons/viruses and that highly specific inhibitors could be engineered to target capsid interfaces.


  • Organizational Affiliation
    • Department of Biochemistry and Molecular Biology, University of Georgia, Athens, Georgia, United States of America.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Capsid protein
A, B
97Saccharomyces cerevisiaeMutation(s): 0
Gene Names: TY1A-MR1YMRCTy1-3 GAGYMR046CYM9532.11C
UniProt
Find proteins for Q04215 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q04215
Go to UniProtKB:  Q04215
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ04215
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free:  0.202 (Depositor), 0.193 (DCC)
  • R-Value Work:  0.180 (Depositor)
Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 31.593α = 101.641
b = 34.332β = 96.351
c = 45.333γ = 109.279
Software Package:
Software NamePurpose
xia2data reduction
DIALSdata reduction
TRUNCATEdata scaling
PHASERphasing
ARP/wARPmodel building
Cootmodel building
REFMACrefinement

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Cancer Research UKUnited KingdomCC2029
Medical Research Council (MRC, United Kingdom)United KingdomCC2029
Wellcome TrustUnited KingdomCC2029

Revision History  (Full details and data files)

  • Version 1.0: 2025-10-08
    Type: Initial release
  • Version 1.1: 2025-10-22
    Changes: Database references
