9O8N | pdb_00009o8n

Crystal structure of 2,3,4,5-tetrahydropyridine-2,6-dicarboxylate N-succinyltransferase (DapD) from Bordetella pertussis

PDB DOI: https://doi.org/10.2210/pdb9O8N/pdb

Classification: TRANSFERASE
Organism(s): Bordetella pertussis Tohama I
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2025-04-16 Released: 2025-04-23
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease, Seattle Structural Genomics Center for Infectious Disease (SSGCID)
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID), National Institutes of Health/Office of the Director

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.59 Å
R-Value Free:
0.179 (Depositor), 0.187 (DCC)
R-Value Work:
0.158 (Depositor), 0.167 (DCC)
R-Value Observed:
0.159 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Crystal structure of 2,3,4,5-tetrahydropyridine-2,6-dicarboxylate N-succinyltransferase (dapD) from Bordetella pertussis

Ung, A.R., Lovell, S., Cooper, A., Battaile, K.P.

To be published.

Macromolecule Content

Total Structure Weight: 30.29 kDa
Atom Count: 2,291
Modeled Residue Count: 271
Deposited Residue Count: 278
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
2,3,4,5-tetrahydropyridine-2,6-dicarboxylate N-succinyltransferase	A	278	Bordetella pertussis Tohama I	Mutation(s): 0 Gene Names: dapD, BP1764 EC: 2.3.1.117
UniProt
Find proteins for P0A4U8 (Bordetella pertussis (strain Tohama I / ATCC BAA-589 / NCTC 13251)) Explore P0A4U8 Go to UniProtKB: P0A4U8
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P0A4U8
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain H [auth A] MOL2 format, chain H [auth A] mmCIF format, chain H [auth A]	H [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Interactions & Density Focus chain H [auth A]
CA Query on CA Download Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain C [auth A] SDF format, chain B [auth A] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] MOL2 format, chain B [auth A] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A] mmCIF format, chain B [auth A]	B [auth A], C [auth A], D [auth A]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A]	E [auth A], F [auth A], G [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.59 Å
R-Value Free: 0.179 (Depositor), 0.187 (DCC)
R-Value Work: 0.158 (Depositor), 0.167 (DCC)
R-Value Observed: 0.159 (Depositor)

Diffraction Data: https://doi.org/10.18430/M39O8N

Space Group: P 6₃

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 97.696	α = 90
b = 97.696	β = 90
c = 78.288	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
Aimless	data scaling
XDS	data reduction
PHASER	phasing
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2025-04-23

Deposition Author(s):

Seattle Structural Genomics Center for Infectious Disease

Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	75N93022C00036
National Institutes of Health/Office of the Director	United States	S10OD030394
