9NGB | pdb_00009ngb

truncated cis-CaaD

PDB DOI: https://doi.org/10.2210/pdb9NGB/pdb

Classification: HYDROLASE
Organism(s): coryneform bacterium
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2025-02-21 Released: 2025-04-02
Deposition Author(s): Silva, K., Geiger, J.H., Draths, K.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.50 Å
R-Value Free:
0.301 (Depositor), 0.299 (DCC)
R-Value Work:
0.209 (Depositor), 0.209 (DCC)
R-Value Observed:
0.218 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9NGB

This is version 1.0 of the entry. See complete history.

Literature

truncated cis-CaaD

Silva, K., Geiger, J.H., Draths, K.

To be published.

Macromolecule Content

Total Structure Weight: 15.23 kDa
Atom Count: 963
Modeled Residue Count: 119
Deposited Residue Count: 134
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Cis-3-chloroacrylic acid dehalogenase	A	134	coryneform bacterium	Mutation(s): 0 Gene Names: cis-caaD
UniProt
Find proteins for Q6VPE5 (coryneform bacterium) Explore Q6VPE5 Go to UniProtKB: Q6VPE5
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q6VPE5
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.50 Å
R-Value Free: 0.301 (Depositor), 0.299 (DCC)
R-Value Work: 0.209 (Depositor), 0.209 (DCC)
R-Value Observed: 0.218 (Depositor)

Space Group: P 6₃

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 59.266	α = 90
b = 59.266	β = 90
c = 57.816	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-04-02

Deposition Author(s):

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2025-04-02
Type: Initial release
