9MEJ | pdb_00009mej

Global structure of hCXCR4 and HIV-2 gp120

• PDB DOI: https://doi.org/10.2210/pdb9MEJ/pdb
• EM Map EMD-48215: EMDB EMDataResource

• Classification: SIGNALING PROTEIN
• Organism(s): Homo sapiens, Human immunodeficiency virus 2
• Expression System: Homo sapiens
• Mutation(s): No


• Deposited: 2024-12-06 Released: 2025-09-10
• Deposition Author(s): Zhang, Z., Patel, D.J.
• Funding Organization(s): National Institutes of Health/National Cancer Institute (NIH/NCI)

---

Experimental Data Snapshot

• Method: ELECTRON MICROSCOPY
• Resolution: 3.99 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Literature

Global structure of hCXCR4 and HIV-2 gp120

Zhang, Z., Patel, D.J.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 5-mer - A4B1 Local Symmetry: Cyclic - C4  (Explore in 3D)
Local Stoichiometry: Homo 4-mer - A4

Local Symmetry: Cyclic - C4  (Explore in 3D)
Local Stoichiometry: Homo 4-mer - A4

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: electron microscopy

Macromolecule Content

• Total Structure Weight: 218.43 kDa
• Atom Count: 12,137
• Modeled Residue Count: 1,495
• Deposited Residue Count: 1,919
• Unique protein chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
C-X-C chemokine receptor type 4	A, B, C, D	360	Homo sapiens	Mutation(s): 0  Gene Names: CXCR4
UniProt & NIH Common Fund Data Resources
Find proteins for P61073 (Homo sapiens) Explore P61073  Go to UniProtKB:  P61073
PHAROS:  P61073 GTEx:  ENSG00000121966

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
gp120	E	479	Human immunodeficiency virus 2	Mutation(s): 0  Gene Names: env
UniProt
Find proteins for P05883 (Human immunodeficiency virus type 2 subtype A (isolate NIH-Z)) Explore P05883  Go to UniProtKB:  P05883

Experimental Data & Validation

Experimental Data

• Method: ELECTRON MICROSCOPY
• Resolution: 3.99 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX	1.20.1_4487

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2025-09-10
Deposition Author(s): Zhang, Z., Patel, D.J.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Cancer Institute (NIH/NCI)	United States	P30CA008748

Revision History

• Version 1.0: 2025-09-10
  Type: Initial release
