9JOF | pdb_00009jof

COMPLEX STRUCTURE OF ENDO-1,3-FUCANASE (FUN168D) FROM GH168 FAMILY WITH FUCOTRIOSE

PDB DOI: https://doi.org/10.2210/pdb9JOF/pdb

Classification: HYDROLASE
Organism(s): Wenyingzhuangia fucanilytica
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2024-09-24 Released: 2024-11-27
Deposition Author(s): Chen, G.N., Chang, Y.G.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.50 Å
R-Value Free:
0.169 (Depositor), 0.169 (DCC)
R-Value Work:
0.141 (Depositor), 0.142 (DCC)
R-Value Observed:
0.141 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9JOF

This is version 1.0 of the entry. See complete history.

Literature

Complex structure of endo-1.3-fucanase (Fun168D) from GH168 family with fucotriose at 1.50 Angstroms resulution.

Chen, G.N., Chang, Y.G.

To be published.

Macromolecule Content

Total Structure Weight: 97.4 kDa
Atom Count: 7,354
Modeled Residue Count: 736
Deposited Residue Count: 846
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
endo-1.3-fucanase	A, B	423	Wenyingzhuangia fucanilytica	Mutation(s): 0 Gene Names: AXE80_08865
UniProt
Find proteins for A0A1B1Y6G8 (Wenyingzhuangia fucanilytica) Explore A0A1B1Y6G8 Go to UniProtKB: A0A1B1Y6G8
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A1B1Y6G8
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
alpha-L-fucopyranose-(1-3)-2,4-di-O-sulfo-alpha-L-fucopyranose-(1-3)-2-O-sulfo-alpha-L-fucopyranose	C, D	3		N/A	Interactions Focus chain C Focus chain D Interactions & Density Focus chain C Focus chain D

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.50 Å
R-Value Free: 0.169 (Depositor), 0.169 (DCC)
R-Value Work: 0.141 (Depositor), 0.142 (DCC)
R-Value Observed: 0.141 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 54.819	α = 90
b = 138.329	β = 113.79
c = 63.062	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
Aimless	data scaling
XDS	data reduction
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-11-27

Deposition Author(s):

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	U22A20542

Revision History (Full details and data files)

Version 1.0: 2024-11-27
Type: Initial release
