9INU | pdb_00009inu

Novel PD-L1/VISTA dual inhibitor as potential immunotherapy agents


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free:
    0.287 (Depositor), 0.287 (DCC)
  • R-Value Work:
    0.244 (Depositor), 0.244 (DCC)
  • R-Value Observed:
    0.248 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9INU

Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history

Literature

Novel PD-L1/VISTA Dual Inhibitor as Potential Immunotherapy Agents.

Sun, C.Cheng, Y.Dong, J.Hu, L.Zhang, Y.Shen, H.Zhang, G.Jiang, B.Adam Youssouf, S.Min, W.Shen, Y.Wang, L.Deng, H.Xiao, Y.Yang, P.

(2025) J Med Chem 68: 156-173

  • DOI: https://doi.org/10.1021/acs.jmedchem.4c01640
  • Primary Citation Related Structures:
    9INU

  • PubMed Abstract:

    Inhibiting the activity of immune checkpoint proteins to reignite the antitumor activity of immune cells has emerged as a pivotal strategy. PD-L1 and VISTA, as critical proteins governing immune regulation, are concurrently upregulated under conditions such as hypoxia. Through a rational drug design process, P17 , a dual-target inhibitor for PD-L1 and VISTA is identified. This inhibitor blocks the signaling pathways of both PD-L1 and VISTA at the protein and cellular levels, thereby reactivating the antitumor function of T cells. P17 displays encouraging attributes in terms of druggability and safety assessments. Notably, P17 demonstrates superior antitumor efficacy compared to single-target inhibitors at equivalent doses in in vivo experiments. More crucially, P17 significantly enhances the infiltration of immune cells. This study not only validates the effectiveness of a dual-target inhibitor strategy against PD-L1 and VISTA, but also identifies P17 as a promising candidate molecule with significant therapeutic potential.


  • Organizational Affiliation
    • State Key Laboratory of Natural Medicines and Jiangsu Key Laboratory of Drug Design and Optimization, China Pharmaceutical University, Nanjing 210009, China.

Macromolecule Content

  • Total Structure Weight: 29.77 kDa
  • Atom Count: 1,980
  • Modeled Residue Count: 251
  • Deposited Residue Count: 256
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Programmed cell death 1 ligand 1
A, B
128Homo sapiensMutation(s): 0
Gene Names: CD274B7H1PDCD1L1PDCD1LG1PDL1
UniProt & NIH Common Fund Data Resources
Find proteins for Q9NZQ7 (Homo sapiens)
Explore Q9NZQ7
Go to UniProtKB:  Q9NZQ7
PHAROS:  Q9NZQ7
GTEx:  ENSG00000120217
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9NZQ7
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
A1D9R

Query on A1D9R



Download:Ideal Coordinates CCD File
C [auth B](2~{S})-2-[[6-methoxy-2-[(2-methyl-3-phenyl-phenyl)amino]pyrimidin-4-yl]methylamino]-3-oxidanyl-propanoic acid
C22 H24 N4 O4
QSHNMTVUJAVARU-IBGZPJMESA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free:  0.287 (Depositor), 0.287 (DCC)
  • R-Value Work:  0.244 (Depositor), 0.244 (DCC)
  • R-Value Observed: 0.248 (Depositor)
Space Group: P 2 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 32.096α = 90
b = 83.603β = 90
c = 96.838γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
Aimlessdata scaling
AutoSolphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2025-03-12
    Type: Initial release
