9IL8 | pdb_00009il8

Crystal Structure of SME-1 Class A Carbapenemase in complex with Durlobactam

• PDB DOI: https://doi.org/10.2210/pdb9IL8/pdb

• Classification: HYDROLASE
• Organism(s): Serratia marcescens
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2024-06-29 Released: 2025-07-02
• Deposition Author(s): Dhankhar, K., Hazra, S.
• Funding Organization(s): Indian Council of Medical Research, Board of Research in Nuclear Sciences (BRNS)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free:
  0.268 (Depositor), 0.272 (DCC)
• R-Value Work:
  0.193 (Depositor), 0.192 (DCC)

Starting Model: experimental

Literature

Crystal Structure of SME-1 Class A Carbapenemase in complex with Durlobactam

Dhankhar, K., Hazra, S.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 61.61 kDa
• Atom Count: 4,284
• Modeled Residue Count: 534
• Deposited Residue Count: 550
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
beta-lactamase	A, B	275	Serratia marcescens	Mutation(s): 0  Gene Names: sme-2, blaSME-1, blaSME-4, blaSME1, SME12620_22 EC: 3.5.2.6
UniProt
Find proteins for P52682 (Serratia marcescens) Explore P52682  Go to UniProtKB:  P52682

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
JXG (Subject of Investigation/LOI)	C [auth A], F [auth B]	(2S,5R)-1-formyl-3-methyl-5-[(sulfooxy)amino]-1,2,5,6-tetrahydropyridine-2-carboxamide C8 H13 N3 O6 S DDVLLOCREWHCBP-RQJHMYQMSA-N
PEG (Subject of Investigation/LOI)	D [auth A], G [auth B]	DI(HYDROXYETHYL)ETHER C4 H10 O3 MTHSVFCYNBDYFN-UHFFFAOYSA-N
CL (Subject of Investigation/LOI)	E [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free:  0.268 (Depositor), 0.272 (DCC)
• R-Value Work:  0.193 (Depositor), 0.192 (DCC)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 35.355	α = 90
b = 50.746	β = 92.705
c = 129.9	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
CrysalisPro	data reduction
CrysalisPro	data scaling
MOLREP	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2025-07-02
Deposition Author(s): Dhankhar, K., Hazra, S.

---

Funding Organization	Location	Grant Number
Indian Council of Medical Research	India	EM/Dev/IG/20/0773/2023
Board of Research in Nuclear Sciences (BRNS)	India	54/14/03/2023-BRNS

Revision History

• Version 1.0: 2025-07-02
  Type: Initial release
