9IL4 | pdb_00009il4

Structure and iron-transporting mechanism of BOCT1

PDB DOI: https://doi.org/10.2210/pdb9IL4/pdb
EM Map EMD-60664: EMDB EMDataResource

Classification: PROTEIN TRANSPORT
Organism(s): Mus spicilegus
Expression System: Homo sapiens
Mutation(s): No

Deposited: 2024-06-29 Released: 2025-07-02
Deposition Author(s): Chen, J., Chen, L.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.33 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 9IL4

This is version 1.1 of the entry. See complete history.

Literature

Structure and iron-transporting mechanism of BOCT1

Chen, J., Chen, L.

To be published.

Macromolecule Content

Total Structure Weight: 111.55 kDa
Atom Count: 4,922
Modeled Residue Count: 666
Deposited Residue Count: 1,040
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Solute carrier family 22 (organic cation transporter), member 17	A [auth B], B [auth A]	520	Mus spicilegus	Mutation(s): 0
UniProt
Find proteins for A0A8C6HEW4 (Mus spicilegus) Explore A0A8C6HEW4 Go to UniProtKB: A0A8C6HEW4
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A8C6HEW4
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
FE2 (Subject of Investigation/LOI) Query on FE2 Download:Ideal Coordinates CCD File SDF format, chain C [auth B] SDF format, chain D [auth A] MOL2 format, chain C [auth B] MOL2 format, chain D [auth A] mmCIF format, chain C [auth B] mmCIF format, chain D [auth A]	C [auth B], D [auth A]	FE (II) ION Fe CWYNVVGOOAEACU-UHFFFAOYSA-N		Interactions Focus chain C [auth B] Focus chain D [auth A] Interactions & Density Focus chain C [auth B] Focus chain D [auth A]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.33 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
RECONSTRUCTION	cryoSPARC	V4
MODEL REFINEMENT	PHENIX

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-07-02

Deposition Author(s):

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	32130048 and 92157301

Revision History (Full details and data files)

Version 1.0: 2025-07-02
Type: Initial release
Version 1.1: 2025-07-23
Changes: Data collection
