9I6T | pdb_00009i6t

14-3-3sigma binding to the ERa peptide and compound 32


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.30 Å
  • R-Value Free:
    0.154 (Depositor), 0.162 (DCC)
  • R-Value Work:
    0.128 (Depositor), 0.143 (DCC)
  • R-Value Observed:
    0.130 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history


Literature

Scaffold-hopping for molecular glues targeting the 14-3-3/ER alpha complex.

Konstantinidou, M.Zingiridis, M.Pennings, M.A.M.Fragkiadakis, M.Virta, J.M.Revalde, J.L.Visser, E.J.Ottmann, C.Brunsveld, L.Neochoritis, C.G.Arkin, M.R.

(2025) Nat Commun 16: 6467-6467

  • DOI: https://doi.org/10.1038/s41467-025-61176-4
  • Primary Citation of Related Structures:
    9I6S, 9I6T, 9I6U, 9I6V, 9I6W, 9I6X, 9I6Y, 9I6Z, 9I70, 9I71, 9I72, 9I73, 9I74, 9I75

  • PubMed Abstract:

    Molecular glues, small molecules that bind cooperatively at a protein-protein interface, have emerged as powerful modalities for the modulation of protein-protein interactions (PPIs) and "undruggable" targets. The systematic identification of new chemical matter with a molecular glue mechanism of action remains a significant challenge in drug discovery. Here, we present a scaffold hopping approach, using as a starting point our previously developed molecular glues for the native 14-3-3/estrogen receptor alpha (ERα) complex. The novel, computationally designed scaffold is based on the Groebke-Blackburn-Bienaymé multi-component reaction (MCR), leading to drug-like analogs with multiple points of variation, thus enabling the rapid derivatization and optimization of the scaffold. Structure-activity relationships (SAR) are developed using orthogonal biophysical assays, such as intact mass spectrometry, TR-FRET and SPR. Rational structure-guided optimization is facilitated by multiple crystal structures of ternary complexes with the glues, 14-3-3 and phospho-peptides mimicking the highly disordered C-terminus of ERα. Cellular stabilization of 14-3-3/ERα for the most potent analogs is confirmed using a NanoBRET assay with full-length proteins in live cells. Our approach highlights the potential of MCR chemistry, combined with scaffold hopping, to drive the development and optimization of unprecedented molecular glue scaffolds.


  • Organizational Affiliation
    • Department of Pharmaceutical Chemistry and Small Molecule Discovery Centre (SMDC) University of California San Francisco (UCSF), San Francisco, CA, USA. markella.konstantinidou@ucsf.edu.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
14-3-3 protein sigma236Homo sapiensMutation(s): 0
Gene Names: SFNHME1
UniProt & NIH Common Fund Data Resources
Find proteins for P31947 (Homo sapiens)
Explore P31947
Go to UniProtKB:  P31947
PHAROS:  P31947
GTEx:  ENSG00000175793
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP31947
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Estrogen receptor5Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P03372 (Homo sapiens)
Explore P03372
Go to UniProtKB:  P03372
PHAROS:  P03372
GTEx:  ENSG00000091831
Entity Groups
UniProt GroupP03372
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
TPO
Query on TPO
B
L-PEPTIDE LINKINGC4 H10 N O6 PTHR
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.30 Å
  • R-Value Free:  0.154 (Depositor), 0.162 (DCC)
  • R-Value Work:  0.128 (Depositor), 0.143 (DCC)
  • R-Value Observed: 0.130 (Depositor)
Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 82.191α = 90
b = 113.033β = 90
c = 62.894γ = 90
Software Package:
Software NamePurpose
PDB-REDOrefinement
autoPROCdata reduction
Aimlessdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM147696

Revision History  (Full details and data files)

  • Version 1.0: 2025-07-30
    Type: Initial release
