9H5G | pdb_00009h5g

PAD12 0N3R:0N4R tau PHF

PDB DOI: https://doi.org/10.2210/pdb9H5G/pdb
EM Map EMD-51884: EMDB EMDataResource

Classification: PROTEIN FIBRIL
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2024-10-22 Released: 2024-12-04
Deposition Author(s): Lovestam, S., Scheres, S.H.W., Goedert, M.
Funding Organization(s): Medical Research Council (MRC, United Kingdom)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.48 Å
Aggregation State: FILAMENT
Reconstruction Method: HELICAL

wwPDB Validation 3D Report Full Report

Validation slider image for 9H5G

This is version 1.0 of the entry. See complete history.

Literature

Twelve phosphomimetic mutations induce the assembly of recombinant full-length human tau into paired helical filaments

Lovestam, S., Scheres, S.H.W., Goedert, M.

To be published.

Macromolecule Content

Total Structure Weight: 222.44 kDa
Atom Count: 3,300
Modeled Residue Count: 432
Deposited Residue Count: 2,112
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Isoform Fetal-tau of Microtubule-associated protein tau	A, B, C, D, E A, B, C, D, E, F	352	Homo sapiens	Mutation(s): 0 Gene Names: MAPT, MAPTL, MTBT1, TAU
UniProt & NIH Common Fund Data Resources
Find proteins for P10636 (Homo sapiens) Explore P10636 Go to UniProtKB: P10636
PHAROS: P10636 GTEx: ENSG00000186868
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P10636
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 2.48 Å
Aggregation State: FILAMENT
Reconstruction Method: HELICAL

EM Software:

Task	Software Package	Version
RECONSTRUCTION	RELION	5

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-12-04

Deposition Author(s):

Scheres, S.H.W.

Funding Organization	Location	Grant Number
Medical Research Council (MRC, United Kingdom)	United Kingdom	--

Revision History (Full details and data files)

Version 1.0: 2024-12-04
Type: Initial release
