9H4B | pdb_00009h4b

Crystal structure of SARS-CoV-2 Mpro in complex with GK-730

PDB DOI: https://doi.org/10.2210/pdb9H4B/pdb

Classification: ANTIVIRAL PROTEIN
Organism(s): Severe acute respiratory syndrome coronavirus 2
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2024-10-18 Released: 2025-10-29
Deposition Author(s): El Kilani, H., Hilgenfeld, R.
Funding Organization(s): European Commission

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free:
0.231 (Depositor), 0.241 (DCC)
R-Value Work:
0.172 (Depositor), 0.185 (DCC)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Crystal structure of SARS-CoV-2 Mpro in complex with GK-730

El Kilani, H., Hilgenfeld, R.

To be published.

Macromolecule Content

Total Structure Weight: 34.47 kDa
Atom Count: 2,551
Modeled Residue Count: 306
Deposited Residue Count: 306
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
3C-like proteinase nsp5	A	306	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 0 Gene Names: rep, 1a-1b EC: 3.4.22.69
UniProt
Find proteins for P0DTD1 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTD1 Go to UniProtKB: P0DTD1
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P0DTD1
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
A1ISK (Subject of Investigation/LOI) Query on A1ISK Download Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	methyl 2-[(1S,2S)-2-[[(2S)-4-methyl-2-[[(2S)-3-methyl-2-(phenylmethoxycarbonylamino)butanoyl]amino]pentanoyl]amino]-1-oxidanyl-3-[(3S)-2-oxidanylidenepyrrolidin-3-yl]propyl]-1,3-thiazole-4-carboxylate C₃₁ H₄₃ N₅ O₈ S VXGLAHXNQFYSAB-ZLCZASCPSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free: 0.231 (Depositor), 0.241 (DCC)
R-Value Work: 0.172 (Depositor), 0.185 (DCC)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 115.777	α = 90
b = 52.896	β = 98.94
c = 45.648	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
Aimless	data scaling
MOLREP	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History & Funding Information

Deposition Data

Released Date: 2025-10-29

Deposition Author(s):

Funding Organization	Location	Grant Number
European Commission	European Union	--

Revision History (Full details and data files)

Version 1.0: 2025-10-29
Type: Initial release
