9GNJ | pdb_00009gnj

Crystal structure of a PP2A B56gamma double phosphorylated BRCA2 complex

PDB DOI: https://doi.org/10.2210/pdb9GNJ/pdb

Classification: SIGNALING PROTEIN
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2024-09-03 Released: 2025-09-24
Deposition Author(s): Miron, S., Zinn-Justin, S.
Funding Organization(s): French Alternative Energies and Atomic Energy Commission (CEA)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.85 Å
R-Value Free:
0.229 (Depositor), 0.241 (DCC)
R-Value Work:
0.197 (Depositor), 0.216 (DCC)
R-Value Observed:
0.198 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Crystal structure of a PP2A B56gamma double phosphorylated BRCA2 complex

Miron, S., Zinn-Justin, S.

To be published.

Macromolecule Content

Total Structure Weight: 42.92 kDa
Atom Count: 2,825
Modeled Residue Count: 338
Deposited Residue Count: 365
Unique protein chains: 2

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Serine/threonine-protein phosphatase 2A 56 kDa regulatory subunit gamma isoform	A	352	Homo sapiens	Mutation(s): 0 Gene Names: PPP2R5C, KIAA0044
UniProt & NIH Common Fund Data Resources
Find proteins for Q13362 (Homo sapiens) Explore Q13362 Go to UniProtKB: Q13362
PHAROS: Q13362 GTEx: ENSG00000078304
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q13362
Sequence Annotations Expand
Reference Sequence

Find similar proteins by: Sequence | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
BRCA2	B	13	Homo sapiens	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Small Molecules

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
SEP Query on SEP	B	L-PEPTIDE LINKING	C₃ H₈ N O₆ P		SER

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.85 Å
R-Value Free: 0.229 (Depositor), 0.241 (DCC)
R-Value Work: 0.197 (Depositor), 0.216 (DCC)
R-Value Observed: 0.198 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 53.3	α = 90
b = 108.12	β = 90
c = 120.03	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
XSCALE	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2025-09-24

Deposition Author(s):

Zinn-Justin, S.

Funding Organization	Location	Grant Number
French Alternative Energies and Atomic Energy Commission (CEA)	France	--

Revision History (Full details and data files)

Version 1.0: 2025-09-24
Type: Initial release
