9F8E | pdb_00009f8e

SLPL/SLPH (H/L) complex from C. difficile SlpA (Ox247_delta_orf2 strain, SLCT11)

PDB DOI: https://doi.org/10.2210/pdb9F8E/pdb

Classification: STRUCTURAL PROTEIN
Organism(s): Clostridioides difficile
Mutation(s): No

Deposited: 2024-05-06 Released: 2025-09-03
Deposition Author(s): Barwinska-Sendra, A., Salgado, P.S.
Funding Organization(s): Medical Research Council (MRC, United Kingdom)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 3.10 Å
R-Value Free:
0.234 (Depositor), 0.235 (DCC)
R-Value Work:
0.178 (Depositor), 0.178 (DCC)
R-Value Observed:
0.181 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9F8E

This is version 1.0 of the entry. See complete history.

Literature

SLPL/SLPH (H/L) complex from C. difficile SlpA (Ox247 strain)

Barwinska-Sendra, A., Salgado, P.S.

To be published.

Macromolecule Content

Total Structure Weight: 124.74 kDa
Atom Count: 8,635
Modeled Residue Count: 1,153
Deposited Residue Count: 1,172
Unique protein chains: 2

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
S-layer protein	A, C	179	Clostridioides difficile	Mutation(s): 0
UniProt
Find proteins for Q2N3V9 (Clostridioides difficile) Explore Q2N3V9 Go to UniProtKB: Q2N3V9
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q2N3V9
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
S-layer protein	B, D	407	Clostridioides difficile	Mutation(s): 0
UniProt
Find proteins for Q2N3V9 (Clostridioides difficile) Explore Q2N3V9 Go to UniProtKB: Q2N3V9
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q2N3V9
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 3.10 Å
R-Value Free: 0.234 (Depositor), 0.235 (DCC)
R-Value Work: 0.178 (Depositor), 0.178 (DCC)
R-Value Observed: 0.181 (Depositor)

Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 47.612	α = 91.64
b = 73.374	β = 95.74
c = 90.799	γ = 96.11

Software Package:

Software Name	Purpose
PHENIX	refinement
PHENIX	refinement
xia2	data reduction
Aimless	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-09-03

Deposition Author(s):

Barwinska-Sendra, A.

Funding Organization	Location	Grant Number
Medical Research Council (MRC, United Kingdom)	United Kingdom	MR/V032151/1

Revision History (Full details and data files)

Version 1.0: 2025-09-03
Type: Initial release
