9EML

SARS-CoV-2 methyltransferase nsp10-16 in complex with SAM and m7GpppA (Cap0-analog)/m7GpppAm (Cap1-analog)

PDB DOI: https://doi.org/10.2210/pdb9EML/pdb

Classification: VIRAL PROTEIN
Organism(s): Severe acute respiratory syndrome coronavirus 2
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2024-03-08 Released: 2024-03-20
Deposition Author(s): Kremling, V., Sprenger, J., Oberthuer, D., Kiene, A.
Funding Organization(s): Other government

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.40 Å
R-Value Free: 0.240
R-Value Work: 0.178
R-Value Observed: 0.179

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

SARS-CoV-2 methyltransferase nsp10-16 in complex with natural and drug-like purine analogs for guiding structure-based drug development

Kremling, V., Sprenger, J., Oberthuer, D., Chapman, H.N., Middendorf, P., Fernandez-Garcia, Y., Ehrt, C., Falke, S., Kiene, A., Klopprogge, B., Scheer, T.E.S., Rarey, M., Barthels, F., Kuehn, S., Guenther, S.

To be published.

Macromolecule Content

Total Structure Weight: 52.42 kDa
Atom Count: 3,723
Modelled Residue Count: 416
Deposited Residue Count: 444
Unique protein chains: 2

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
2'-O-methyltransferase nsp16	A	304	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 0 Gene Names: rep, 1a-1b EC: 2.1.1.57
UniProt
Find proteins for P0DTD1 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTD1 Go to UniProtKB: P0DTD1
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P0DTD1
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Non-structural protein 10	B	140	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 0 Gene Names: rep, 1a-1b
UniProt
Find proteins for P0DTD1 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTD1 Go to UniProtKB: P0DTD1
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P0DTD1
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 7 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
V9G (Subject of Investigation/LOI) Query on V9G Download Ideal Coordinates CCD File SDF format, chain R [auth A] MOL2 format, chain R [auth A]	R [auth A]	7-METHYL-GUANOSINE-5'-TRIPHOSPHATE-5'-(2'-O-METHYL)-ADENOSINE C₂₂ H₃₂ N₁₀ O₁₇ P₃ WZAAWBDISKLAIE-NAGRZYTCSA-N		Interactions Focus chain R [auth A] Interactions & Density Focus chain R [auth A]
GTA (Subject of Investigation/LOI) Query on GTA Download Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A]	C [auth A]	P1-7-METHYLGUANOSINE-P3-ADENOSINE-5',5'-TRIPHOSPHATE C₂₁ H₃₀ N₁₀ O₁₇ P₃ QQOHNVHGNZYSBP-XPWFQUROSA-O		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]
SAM Query on SAM Download Ideal Coordinates CCD File SDF format, chain E [auth A] MOL2 format, chain E [auth A]	E [auth A]	S-ADENOSYLMETHIONINE C₁₅ H₂₂ N₆ O₅ S MEFKEPWMEQBLKI-FCKMPRQPSA-N		Interactions Focus chain E [auth A] Interactions & Density Focus chain E [auth A]
EDT Query on EDT Download Ideal Coordinates CCD File SDF format, chain O [auth A] MOL2 format, chain O [auth A]	O [auth A]	{[-(BIS-CARBOXYMETHYL-AMINO)-ETHYL]-CARBOXYMETHYL-AMINO}-ACETIC ACID C₁₀ H₁₆ N₂ O₈ KCXVZYZYPLLWCC-UHFFFAOYSA-N		Interactions Focus chain O [auth A] Interactions & Density Focus chain O [auth A]
MES Query on MES Download Ideal Coordinates CCD File SDF format, chain F [auth A] MOL2 format, chain F [auth A]	F [auth A]	2-(N-MORPHOLINO)-ETHANESULFONIC ACID C₆ H₁₃ N O₄ S SXGZJKUKBWWHRA-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Interactions & Density Focus chain F [auth A]
ZN Query on ZN Download Ideal Coordinates CCD File SDF format, chain T [auth B] SDF format, chain S [auth B] MOL2 format, chain T [auth B] MOL2 format, chain S [auth B]	S [auth B], T [auth B]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain S [auth B] Focus chain T [auth B] Interactions & Density Focus chain S [auth B] Focus chain T [auth B]
EDO Query on EDO Download Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain G [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain L [auth A] SDF format, chain M [auth A] SDF format, chain N [auth A] SDF format, chain P [auth A] SDF format, chain U [auth B] SDF format, chain V [auth B] SDF format, chain H [auth A] SDF format, chain Q [auth A] MOL2 format, chain D [auth A] MOL2 format, chain G [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain L [auth A] MOL2 format, chain M [auth A] MOL2 format, chain N [auth A] MOL2 format, chain P [auth A] MOL2 format, chain U [auth B] MOL2 format, chain V [auth B] MOL2 format, chain H [auth A] MOL2 format, chain Q [auth A]	D [auth A] G [auth A] H [auth A] I [auth A] J [auth A] D [auth A], G [auth A], H [auth A], I [auth A], J [auth A], K [auth A], L [auth A], M [auth A], N [auth A], P [auth A], Q [auth A], U [auth B], V [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain P [auth A] Focus chain Q [auth A] Focus chain U [auth B] Focus chain V [auth B] Interactions & Density Focus chain D [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain P [auth A] Focus chain Q [auth A] Focus chain U [auth B] Focus chain V [auth B]
