9DCG | pdb_00009dcg

Crystal Structure of the Thiol:Disulfide Interchange Protein DsbC from Vibrio cholerae

PDB DOI: https://doi.org/10.2210/pdb9DCG/pdb

Classification: OXIDOREDUCTASE
Organism(s): Vibrio cholerae O1 biovar El Tor str. N16961
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2024-08-26 Released: 2024-09-04
Deposition Author(s): Kim, Y., Maltseva, N., Shatsman, S., Joachimiak, A., Center for Structural Biology of Infectious Diseases (CSBID)
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.09 Å
R-Value Free:
0.257 (Depositor), 0.257 (DCC)
R-Value Work:
0.214 (Depositor), 0.214 (DCC)
R-Value Observed:
0.217 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9DCG

This is version 1.1 of the entry. See complete history.

Literature

Crystal Structure of the Thiol:Disulfide Interchange Protein DsbC from Vibrio cholerae

Kim, Y., Maltseva, N., Shatsman, S., Joachimiak, A., Center for Structural Biology of Infectious Diseases (CSBID)

To be published.

Macromolecule Content

Total Structure Weight: 32.21 kDa
Atom Count: 2,289
Modeled Residue Count: 284
Deposited Residue Count: 284
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Thiol:disulfide interchange protein	A, B	142	Vibrio cholerae O1 biovar El Tor str. N16961	Mutation(s): 0 Gene Names: VC_2418
UniProt
Find proteins for Q9KPF0 (Vibrio cholerae serotype O1 (strain ATCC 39315 / El Tor Inaba N16961)) Explore Q9KPF0 Go to UniProtKB: Q9KPF0
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9KPF0
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain G [auth B] MOL2 format, chain G [auth B] mmCIF format, chain G [auth B]	G [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain G [auth B] Interactions & Density Focus chain G [auth B]
FMT Query on FMT Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	FORMIC ACID C H₂ O₂ BDAGIHXWWSANSR-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain H [auth B] SDF format, chain F [auth A] SDF format, chain E [auth A] SDF format, chain D [auth A] MOL2 format, chain H [auth B] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] mmCIF format, chain H [auth B] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A]	D [auth A], E [auth A], F [auth A], H [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain H [auth B] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain H [auth B]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.09 Å
R-Value Free: 0.257 (Depositor), 0.257 (DCC)
R-Value Work: 0.214 (Depositor), 0.214 (DCC)
R-Value Observed: 0.217 (Depositor)

Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 37.499	α = 64.074
b = 43.744	β = 80.794
c = 47.851	γ = 79.862

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling
HKL-3000	phasing
MOLREP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-09-04

Deposition Author(s):

Center for Structural Biology of Infectious Diseases (CSBID)

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	--

Revision History (Full details and data files)

Version 1.0: 2024-09-04
Type: Initial release
Version 1.1: 2024-10-23
Changes: Structure summary
