9DAG | pdb_00009dag

Crystal structure of NDM-1 complexed with compound 13

PDB DOI: https://doi.org/10.2210/pdb9DAG/pdb

Classification: HYDROLASE
Organism(s): Klebsiella pneumoniae
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2024-08-22 Released: 2025-09-03
Deposition Author(s): Jacobs, L.M.C., Chen, Y.
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.84 Å
R-Value Free:
0.222 (Depositor), 0.226 (DCC)
R-Value Work:
0.163 (Depositor), 0.170 (DCC)
R-Value Observed:
0.165 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Hit to Lead Optimization of Heteroaryl Phosphonates Reversible, Broad-Spectrum Inhibitors of Serine and Metallo Carbapenemases.

Jacobs, L.M.C., Chen, Y., Renslo, A.

To be published.

Macromolecule Content

Total Structure Weight: 25.6 kDa
Atom Count: 1,889
Modeled Residue Count: 229
Deposited Residue Count: 233
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Metallo-beta-lactamase type 2	A	233	Klebsiella pneumoniae	Mutation(s): 0 Gene Names: blaNDM-1 EC: 3.5.2.6
UniProt
Find proteins for C7C422 (Klebsiella pneumoniae) Explore C7C422 Go to UniProtKB: C7C422
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	C7C422
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
A1A3B (Subject of Investigation/LOI) Query on A1A3B Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain B [auth A] MOL2 format, chain E [auth A] MOL2 format, chain B [auth A] mmCIF format, chain E [auth A] mmCIF format, chain B [auth A]	B [auth A], E [auth A]	{[6-fluoro-1-methyl-2-oxo-7-(pyrrolidin-1-yl)-1,2-dihydroquinolin-4-yl]methyl}phosphonic acid C₁₅ H₁₈ F N₂ O₄ P MLFCPSYHIKBWQX-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain E [auth A] Interactions & Density Focus chain B [auth A] Focus chain E [auth A]
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A]	C [auth A], D [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Interactions & Density Focus chain C [auth A] Focus chain D [auth A]
ZN Query on ZN Download Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A]	F [auth A], G [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Focus chain G [auth A] Interactions & Density Focus chain F [auth A] Focus chain G [auth A]
