9CGQ | pdb_00009cgq

Rabbit RyR1 disease mutant Y523S in complex with FKBP12.6, nanodisc and inhibitor dantrolene in the presence of activating calcium

• PDB DOI: https://doi.org/10.2210/pdb9CGQ/pdb
• EM Map EMD-45585: EMDB EMDataResource

• Classification: MEMBRANE PROTEIN
• Organism(s): Oryctolagus cuniculus, Homo sapiens
• Expression System: Homo sapiens, Escherichia coli 'BL21-Gold(DE3)pLysS AG
• Mutation(s): Yes


• Deposited: 2024-06-30 Released: 2024-12-11
• Deposition Author(s): Iyer, K.A., Samso, M.
• Funding Organization(s): National Institutes of Health/National Institute of Arthritis and Musculoskeletal and Skin Diseases (NIH/NIAMS), American Heart Association, Other private, National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

---

Experimental Data Snapshot

• Method: ELECTRON MICROSCOPY
• Resolution: 3.23 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Starting Model: experimental

Literature

Manuscript in preparation

Iyer, K.A., Kobayashi, T., Murayama, T., Samso, M.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C4  (Explore in 3D)
Global Stoichiometry: Hetero 8-mer - A4B4

Biological assembly 1 assigned by authors and generated by (software)

Biological Assembly Evidence: electron microscopy

Macromolecule Content

• Total Structure Weight: 2,313.71 kDa
• Atom Count: 129,760
• Modeled Residue Count: 17,048
• Deposited Residue Count: 20,576
• Unique protein chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Ryanodine receptor 1	A, B, C, D	5,037	Oryctolagus cuniculus	Mutation(s): 1  Gene Names: RYR1
UniProt
Find proteins for P11716 (Oryctolagus cuniculus) Explore P11716  Go to UniProtKB:  P11716

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Peptidyl-prolyl cis-trans isomerase FKBP1B	E, F, G, H	107	Homo sapiens	Mutation(s): 0  Gene Names: FKBP1B, FKBP12.6, FKBP1L, FKBP9, OTK4 EC: 5.2.1.8
UniProt & NIH Common Fund Data Resources
Find proteins for P68106 (Homo sapiens) Explore P68106  Go to UniProtKB:  P68106
PHAROS:  P68106 GTEx:  ENSG00000119782

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ATP (Subject of Investigation/LOI)	J [auth A], N [auth B], R [auth C], V [auth D]	ADENOSINE-5'-TRIPHOSPHATE C10 H16 N5 O13 P3 ZKHQWZAMYRWXGA-KQYNXXCUSA-N
U1C (Subject of Investigation/LOI)	L [auth A], P [auth B], T [auth C], X [auth D]	Dantrolene C14 H10 N4 O5 OZOMQRBLCMDCEG-CHHVJCJISA-N
ZN (Subject of Investigation/LOI)	I [auth A], M [auth B], Q [auth C], U [auth D]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N
CA (Subject of Investigation/LOI)	K [auth A], O [auth B], S [auth C], W [auth D]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: ELECTRON MICROSCOPY
• Resolution: 3.23 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX	1.20_4459:

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2024-12-11
Deposition Author(s): Iyer, K.A., Samso, M.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of Arthritis and Musculoskeletal and Skin Diseases (NIH/NIAMS)	United States	R01 AR068431
American Heart Association	United States	19POST34430178
Other private		MDA 352845
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	U24 GM116789
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	U24 GM116790

Revision History

• Version 1.0: 2024-12-11
  Type: Initial release
