9BHR | pdb_00009bhr

Crystal structure of the WDR domain of human DCAF1 in complex with OICR-40155 compound

PDB DOI: https://doi.org/10.2210/pdb9BHR/pdb

Classification: TRANSFERASE
Organism(s): Homo sapiens
Expression System: Spodoptera frugiperda
Mutation(s): Yes

Deposited: 2024-04-21 Released: 2024-05-08
Deposition Author(s): kimani, S., Dong, A., Li, Y., Seitova, A., Al-Awar, R., Krausser, C., Wilson, B., Ackloo, S., Arrowsmith, C.H., Edwards, A.M., Halabelian, L., Structural Genomics Consortium (SGC)
Funding Organization(s): Other private

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.62 Å
R-Value Free:
0.187 (Depositor)
R-Value Work:
0.148 (Depositor)
R-Value Observed:
0.150 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9BHR

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Crystal structure of the WDR domain of human DCAF1 in complex with OICR-40155 compound

kimani, S., Dong, A., Li, Y., Seitova, A., Al-Awar, R., Krausser, C., Wilson, B., Ackloo, S., Arrowsmith, C.H., Edwards, A.M., Halabelian, L.

To be published.

Macromolecule Content

Total Structure Weight: 72.32 kDa
Atom Count: 5,294
Modeled Residue Count: 596
Deposited Residue Count: 630
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
DDB1- and CUL4-associated factor 1	A, B	315	Homo sapiens	Mutation(s): 2 Gene Names: DCAF1, KIAA0800, RIP, VPRBP EC: 2.7.11.1
UniProt & NIH Common Fund Data Resources
Find proteins for Q9Y4B6 (Homo sapiens) Explore Q9Y4B6 Go to UniProtKB: Q9Y4B6
PHAROS: Q9Y4B6 GTEx: ENSG00000145041
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9Y4B6
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
A1API (Subject of Investigation/LOI) Query on A1API Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth B] MOL2 format, chain C [auth A] MOL2 format, chain D [auth B] mmCIF format, chain C [auth A] mmCIF format, chain D [auth B]	C [auth A], D [auth B]	(4P)-N-[(1S)-3-amino-1-(3-chloro-4-fluorophenyl)-3-oxopropyl]-4-(4-chloro-2-fluorophenyl)-5-{(1E)-3-[(2-methoxyethyl)amino]-3-oxoprop-1-en-1-yl}-1H-pyrrole-3-carboxamide C₂₆ H₂₄ Cl₂ F₂ N₄ O₄ GUWRELPYWXMMMM-WMWRJIBUSA-N		Interactions Focus chain C [auth A] Focus chain D [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.62 Å
R-Value Free: 0.187 (Depositor)
R-Value Work: 0.148 (Depositor)
R-Value Observed: 0.150 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 48.769	α = 90
b = 87.869	β = 97.44
c = 73.243	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-3000	data scaling
REFMAC	phasing
HKL-3000	data reduction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-05-08

Deposition Author(s):

Arrowsmith, C.H.

Structural Genomics Consortium (SGC)

Funding Organization	Location	Grant Number
Other private		--

Revision History (Full details and data files)

Version 1.0: 2024-05-08
Type: Initial release
