8ZSE | pdb_00008zse

Crystal Structure of SARS CoV-2 Papain-like Protease PLpro-C111S in Complex with GZNL-2002

PDB DOI: https://doi.org/10.2210/pdb8ZSE/pdb

Classification: HYDROLASE
Organism(s): Severe acute respiratory syndrome coronavirus 2
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2024-06-05 Released: 2025-06-11
Deposition Author(s): Lu, Y., Shang, J.
Funding Organization(s): Ministry of Science and Technology (MoST, China), National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.80 Å
R-Value Free:
0.257 (Depositor), 0.258 (DCC)
R-Value Work:
0.209 (Depositor), 0.216 (DCC)
R-Value Observed:
0.211 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Crystal Structure of SARS CoV-2 Papain-like Protease PLpro-C111S in Complex with GZNL-2002

Lu, Y., Shang, J.

To be published.

Macromolecule Content

Total Structure Weight: 72.75 kDa
Atom Count: 5,041
Modeled Residue Count: 624
Deposited Residue Count: 632
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Papain-like protease nsp3	A, B	316	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 1 Gene Names: rep, 1a-1b EC: 3.4.19.12 (PDB Primary Data), 3.4.22 (PDB Primary Data)
UniProt
Find proteins for P0DTD1 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTD1 Go to UniProtKB: P0DTD1
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P0DTD1
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
A1L2A (Subject of Investigation/LOI) Query on A1L2A Download Ideal Coordinates CCD File SDF format, chain L [auth B] SDF format, chain G [auth A] MOL2 format, chain L [auth B] MOL2 format, chain G [auth A] mmCIF format, chain L [auth B] mmCIF format, chain G [auth A]	G [auth A], L [auth B]	2-methyl-5-(4-methylpiperazin-1-yl)-~{N}-(1-quinolin-4-ylcyclopropyl)benzamide C₂₅ H₂₈ N₄ O LZLUSPLHJLQEPU-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Focus chain L [auth B] Interactions & Density Focus chain G [auth A] Focus chain L [auth B]
ZN Query on ZN Download Ideal Coordinates CCD File SDF format, chain K [auth B] SDF format, chain J [auth B] SDF format, chain I [auth B] SDF format, chain H [auth B] SDF format, chain F [auth A] SDF format, chain E [auth A] SDF format, chain D [auth A] SDF format, chain C [auth A] MOL2 format, chain K [auth B] MOL2 format, chain J [auth B] MOL2 format, chain I [auth B] MOL2 format, chain H [auth B] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] mmCIF format, chain K [auth B] mmCIF format, chain J [auth B] mmCIF format, chain I [auth B] mmCIF format, chain H [auth B] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A]	C [auth A] D [auth A] E [auth A] F [auth A] H [auth B] C [auth A], D [auth A], E [auth A], F [auth A], H [auth B], I [auth B], J [auth B], K [auth B]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain H [auth B] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain H [auth B] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.80 Å
R-Value Free: 0.257 (Depositor), 0.258 (DCC)
R-Value Work: 0.209 (Depositor), 0.216 (DCC)
R-Value Observed: 0.211 (Depositor)

Space Group: P 4₁ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 95.18	α = 90
b = 95.18	β = 90
c = 232.35	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
Aimless	data scaling
autoPROC	data reduction
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History & Funding Information

Deposition Data

Released Date: 2025-06-11

Deposition Author(s):

Lu, Y.

Shang, J.

Funding Organization	Location	Grant Number
Ministry of Science and Technology (MoST, China)	China	GZNL2023401008
Ministry of Science and Technology (MoST, China)	China	SRPG22-002
Ministry of Science and Technology (MoST, China)	China	SRPG22-003
National Natural Science Foundation of China (NSFC)	China	82170473
