8YLB | pdb_00008ylb

Cocrystal structures of agonists compound 1 with HsClpP


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.15 Å
  • R-Value Free:
    0.260 (Depositor), 0.303 (DCC)
  • R-Value Work:
    0.207 (Depositor)
  • R-Value Observed:
    0.208 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8YLB

Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history

Literature

Rational Design of a Novel Class of Human ClpP Agonists through a Ring-Opening Strategy with Enhanced Antileukemia Activity.

Xiang, X.Dai, Z.Luo, B.Zhao, N.Liu, S.Sui, J.Huang, J.Zhou, Y.Gu, J.Zhang, J.Yang, T.Bao, R.Luo, Y.

(2024) J Med Chem 67: 6769-6792

  • DOI: https://doi.org/10.1021/acs.jmedchem.4c00338
  • Primary Citation Related Structures:
    8YLB

  • PubMed Abstract:

    The activation of Homo sapiens Casein lysing protease P (HsClpP) by a chemical or genetic strategy has been proved to be a new potential therapy in acute myeloid leukemia (AML). However, limited efficacy has been achieved with classic agonist imipridone ONC201 . Here, a novel class of HsClpP agonists is designed and synthesized using a ring-opening strategy based on the lead compound 1 reported in our previous study. Among these novel scaffold agonists, compound 7k exhibited remarkably enhanced proteolytic activity of HsClpP (EC 50 = 0.79 ± 0.03 μM) and antitumor activity in vitro (IC 50 = 0.038 ± 0.003 μM). Moreover, the intraperitoneal administration of compound 7k markedly suppressed tumor growth in Mv4-11 xenograft models, achieving a tumor growth inhibition rate of 88%. Concurrently, 7k displayed advantageous pharmacokinetic properties in vivo . This study underscores the promise of compound 7k as a significant HsClpP agonist and an antileukemia drug candidate, warranting further exploration for AML treatment.


  • Organizational Affiliation
    • State Key Laboratory of Biotherapy and Cancer Center, West China Hospital, Sichuan University, Chengdu 610041, China.

Macromolecule Content

  • Total Structure Weight: 342.71 kDa
  • Atom Count: 19,440
  • Modeled Residue Count: 2,389
  • Deposited Residue Count: 3,080
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
ATP-dependent Clp protease proteolytic subunit, mitochondrial
A, B, C, D, E
A, B, C, D, E, F, G, H, I, J, K, L, M, N
220Homo sapiensMutation(s): 0
Gene Names: CLPP
EC: 3.4.21.92
UniProt & NIH Common Fund Data Resources
Find proteins for Q16740 (Homo sapiens)
Explore Q16740
Go to UniProtKB:  Q16740
PHAROS:  Q16740
GTEx:  ENSG00000125656
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ16740
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
A1LZA
(Subject of Investigation/LOI)

Query on A1LZA



Download:Ideal Coordinates CCD File
AA [auth M]
BA [auth N]
O [auth A]
P [auth B]
Q [auth C]
AA [auth M],
BA [auth N],
O [auth A],
P [auth B],
Q [auth C],
R [auth D],
S [auth E],
T [auth F],
U [auth G],
V [auth H],
W [auth I],
X [auth J],
Y [auth K],
Z [auth L]
5-[(2-methylphenyl)methyl]-11-(phenylmethyl)-2,5,7,11-tetrazatricyclo[7.4.0.0^{2,6}]trideca-1(9),6-dien-8-one
C24 H26 N4 O
CPQVAKZHOMXNHY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.15 Å
  • R-Value Free:  0.260 (Depositor), 0.303 (DCC)
  • R-Value Work:  0.207 (Depositor)
  • R-Value Observed: 0.208 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 120.239α = 90
b = 96.742β = 94.44
c = 124.542γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
Aimlessdata scaling
XDSdata reduction
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2024-05-15
    Type: Initial release
