8XPX | pdb_00008xpx

The Crystal Structure of PARP12 from Biortus.

PDB DOI: https://doi.org/10.2210/pdb8XPX/pdb

Classification: TRANSFERASE
Organism(s): Homo sapiens
Expression System: Spodoptera frugiperda
Mutation(s): No

Deposited: 2024-01-04 Released: 2024-03-06
Deposition Author(s): Wang, F., Cheng, W., Lv, Z., Qi, J., Shen, Z.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.75 Å
R-Value Free:
0.194 (Depositor), 0.200 (DCC)
R-Value Work:
0.164 (Depositor), 0.170 (DCC)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

The Crystal Structure of PARP12 from Biortus.

Wang, F., Cheng, W., Lv, Z., Qi, J., Shen, Z.

To be published.

Macromolecule Content

Total Structure Weight: 45.54 kDa
Atom Count: 3,350
Modeled Residue Count: 363
Deposited Residue Count: 392
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Protein mono-ADP-ribosyltransferase PARP12	A, B	196	Homo sapiens	Mutation(s): 0 Gene Names: PARP12, ZC3HDC1 EC: 2.4.2
UniProt & NIH Common Fund Data Resources
Find proteins for Q9H0J9 (Homo sapiens) Explore Q9H0J9 Go to UniProtKB: Q9H0J9
PHAROS: Q9H0J9 GTEx: ENSG00000059378
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q9H0J9
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PEG (Subject of Investigation/LOI) Query on PEG Download Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain J [auth B] MOL2 format, chain D [auth A] MOL2 format, chain J [auth B] mmCIF format, chain D [auth A] mmCIF format, chain J [auth B]	D [auth A], J [auth B]	DI(HYDROXYETHYL)ETHER C₄ H₁₀ O₃ MTHSVFCYNBDYFN-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain J [auth B] Interactions & Density Focus chain D [auth A] Focus chain J [auth B]
EDO (Subject of Investigation/LOI) Query on EDO Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain H [auth A] MOL2 format, chain C [auth A] MOL2 format, chain H [auth A] mmCIF format, chain C [auth A] mmCIF format, chain H [auth A]	C [auth A], H [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain H [auth A] Interactions & Density Focus chain C [auth A] Focus chain H [auth A]
ACT (Subject of Investigation/LOI) Query on ACT Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain I [auth A] SDF format, chain K [auth B] SDF format, chain L [auth B] SDF format, chain M [auth B] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain I [auth A] MOL2 format, chain K [auth B] MOL2 format, chain L [auth B] MOL2 format, chain M [auth B] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain I [auth A] mmCIF format, chain K [auth B] mmCIF format, chain L [auth B] mmCIF format, chain M [auth B]	E [auth A] F [auth A] G [auth A] I [auth A] K [auth B] E [auth A], F [auth A], G [auth A], I [auth A], K [auth B], L [auth B], M [auth B]	ACETATE ION C₂ H₃ O₂ QTBSBXVTEAMEQO-UHFFFAOYSA-M		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain I [auth A] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth B] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain I [auth A] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth B]
