8XJJ | pdb_00008xjj

Co-crystal structure of SOS-1 and a potent, selective and orally bioavailable SOS1 inhibitor RGT-018


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free:
    0.264 (Depositor), 0.271 (DCC)
  • R-Value Work:
    0.220 (Depositor), 0.228 (DCC)
  • R-Value Observed:
    0.222 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8XJJ

Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history

Literature

Discovery of RGT-018: A Potent, Selective, and Orally Bioavailable SOS1 Inhibitor for KRAS-Driven Cancers.

Xiao, F.Wang, K.Wang, X.Li, H.Hu, Z.Ren, X.Huang, W.Feng, T.Yao, L.Lin, J.Li, C.Zhang, Z.Mei, L.Zhu, X.Zhong, W.Xie, Z.

(2024) Mol Cancer Ther 23: 1703-1716

  • DOI: https://doi.org/10.1158/1535-7163.MCT-24-0049
  • Primary Citation Related Structures:
    8XJJ

  • PubMed Abstract:

    KRAS is the most frequently dysregulated oncogene with high prevalence in NSCLC, colorectal cancer, and pancreatic cancer. FDA-approved sotorasib and adagrasib provide breakthrough therapies for cancer patients with KRASG12C mutation. However, there is still high unmet medical need for new agents targeting broader KRAS-driven tumors. An emerging and promising opportunity is to develop a pan KRAS inhibitor by suppressing the upstream protein SOS1. SOS1 is a key activator of KRAS and facilitates the conversion of GDP-bound KRAS state to GTP-bound KRAS state. Binding to its catalytic domain, small molecule SOS1 inhibitor has demonstrated the ability to suppress KRAS activation and cancer cell proliferation. RGT-018, a potent and selective SOS1 inhibitor, was identified with optimal drug-like properties. In vitro, RGT-018 blocked the interaction of KRAS:SOS1 with single digit nM potency and is highly selective against SOS2. RGT-018 inhibited KRAS signaling and the proliferation of a broad spectrum of KRAS-driven cancer cells as a single agent in vitro. Further enhanced anti-proliferation activity was observed when RGT-018 was combined with MEK, KRASG12C, EGFR or CDK4/6 inhibitors. Oral administration of RGT-018 inhibited tumor growth and suppressed KRAS signaling in tumor xenografts in vivo. Combination with MEK or KRASG12C inhibitors led to significant tumor regression. Furthermore, RGT-018 overcame the resistance to the approved KRASG12C inhibitors caused by clinically acquired KRAS mutations either as a single agent or in combination. RGT-018 displayed promising pharmacological properties for combination with targeted agents to treat a broader KRAS-driven patient population.


  • Organizational Affiliation
    • Regor Therapeutics Group, Shanghai, China.

Macromolecule Content

  • Total Structure Weight: 69.27 kDa
  • Atom Count: 4,109
  • Modeled Residue Count: 473
  • Deposited Residue Count: 590
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Son of sevenless homolog 1590Homo sapiensMutation(s): 4
Gene Names: SOS1
UniProt & NIH Common Fund Data Resources
Find proteins for Q07889 (Homo sapiens)
Explore Q07889
Go to UniProtKB:  Q07889
PHAROS:  Q07889
GTEx:  ENSG00000115904
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ07889
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
A1LVJ
(Subject of Investigation/LOI)

Query on A1LVJ



Download:Ideal Coordinates CCD File
B [auth A]5-[4-[[(1~{R})-1-[3-[bis(fluoranyl)methyl]-2-fluoranyl-phenyl]ethyl]amino]-2-methyl-6-morpholin-4-yl-7-oxidanylidene-pyrido[4,3-d]pyrimidin-8-yl]pyridine-2-carbonitrile
C27 H24 F3 N7 O2
HRMKBFIINYRRDO-OAHLLOKOSA-N
EDO

Query on EDO



Download:Ideal Coordinates CCD File
C [auth A]
D [auth A]
E [auth A]
F [auth A]
G [auth A]
C [auth A],
D [auth A],
E [auth A],
F [auth A],
G [auth A],
H [auth A],
I [auth A],
J [auth A],
K [auth A],
L [auth A],
M [auth A],
N [auth A]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free:  0.264 (Depositor), 0.271 (DCC)
  • R-Value Work:  0.220 (Depositor), 0.228 (DCC)
  • R-Value Observed: 0.222 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 40.76α = 90
b = 83.85β = 90
c = 179.02γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
Aimlessdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data

  • Released Date: 2024-08-14
  • Deposition Author(s): Ren, X.

Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2024-08-14
    Type: Initial release
  • Version 1.1: 2024-12-18
    Changes: Database references, Structure summary
