8WY3

Crystal Structure of the first bromodomain of human BRD4 in complex with the inhibitor 21


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.78 Å
  • R-Value Free: 0.234
  • R-Value Work: 0.186
  • R-Value Observed: 0.188

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Discovery of Novel Phenoxyaryl Pyridones as Bromodomain and Extra-Terminal Domain (BET) Inhibitors with High Selectivity for the Second Bromodomain (BD2) to Potentially Treat Acute Myeloid Leukemia.

Jiang, W.Hou, Q.Xu, H.Yang, K.Wang, X.Zhang, K.Zeng, Y.Li, W.Wang, B.Luo, G.Zhao, X.Shen, H.Xu, Y.Wu, X.

(2024) J Med Chem 67: 1513-1532

  • DOI: https://doi.org/10.1021/acs.jmedchem.3c02104
  • Primary Citation of Related Structures:
    8WXY, 8WY3, 8WY7, 8WYG

  • PubMed Abstract:

    Bromodomain-selective BET inhibition has emerged as a promising strategy to improve the safety profiles of pan -BET inhibitors. Herein, we report the discovery of potent phenoxyaryl pyridones as highly BD2-selective BET inhibitors. Compound 23 (IC 50 = 2.9 nM) exhibited a comparable BRD4 BD2 inhibitory activity relative to 10 (IC 50 = 1.0 nM) and remarkably improved selectivity over BRD4 BD1 ( 23 : 2583-fold; 10 : 344-fold). This lead compound significantly inhibited the proliferation of acute myeloid leukemia (AML) cell lines through induction of G0/G1 arrest and apoptosis in vitro . Excellent in vivo antitumor efficacy with 23 was achieved in an MV;411 mouse xenograft model. Pleasingly, compound 23 (hERG IC 50 > 30 μM) mitigated the inhibition of the human ether-à-go-go-related gene (hERG) ion channel compared with 10 (hERG IC 50 = 2.8 μM). This work provides a promising BD2-selective lead for the development of more effective and safe BET inhibitors as anticancer agents.


  • Organizational Affiliation

    Department of Medicinal Chemistry, School of Pharmacy, China Pharmaceutical University, Nanjing 211198, China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Bromodomain-containing protein 4
A, B, C
141Homo sapiensMutation(s): 0
Gene Names: BRD4HUNK1
UniProt & NIH Common Fund Data Resources
Find proteins for O60885 (Homo sapiens)
Explore O60885
Go to UniProtKB:  O60885
GTEx:  ENSG00000141867
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO60885
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
XHE (Subject of Investigation/LOI)
Query on XHE

Download Ideal Coordinates CCD File
D [auth A],
E [auth B],
F [auth C]
~{N}-cyclopropyl-2-[[5-[2-(4-fluoranyl-2,6-dimethyl-phenoxy)-5-(2-oxidanylpropan-2-yl)phenyl]-1-methyl-2-oxidanylidene-pyridin-4-yl]amino]ethanamide
C28 H32 F N3 O4
MPIHILGEFGFWAJ-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.78 Å
  • R-Value Free: 0.234
  • R-Value Work: 0.186
  • R-Value Observed: 0.188
  • Space Group: P 61 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 140.409α = 90
b = 140.409β = 90
c = 134.482γ = 120
Software Package:
Software NamePurpose
REFMACrefinement
Aimlessdata scaling
XDSdata reduction
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China22307116

Revision History  (Full details and data files)

  • Version 1.0: 2024-01-24
    Type: Initial release
  • Version 1.1: 2024-02-07
    Changes: Database references, Refinement description
