8UQU | pdb_00008uqu

Crystal Structure of N-terminal Domain of Fic Family Protein from Bordetella bronchiseptica

PDB DOI: https://doi.org/10.2210/pdb8UQU/pdb

Classification: TRANSFERASE
Organism(s): Bordetella bronchiseptica
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2023-10-24 Released: 2024-10-30
Deposition Author(s): Minasov, G., Shuvalova, L., Brunzelle, J.S., Kiryukhina, O., Satchell, K.J.F., Center for Structural Biology of Infectious Diseases (CSBID)
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.95 Å
R-Value Free:
0.207 (Depositor), 0.203 (DCC)
R-Value Work:
0.178 (Depositor), 0.177 (DCC)
R-Value Observed:
0.179 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8UQU

This is version 1.0 of the entry. See complete history.

Literature

Crystal Structure of N-terminal Domain of Fic Family Protein from Bordetella bronchiseptica

Minasov, G., Shuvalova, L., Brunzelle, J.S., Kiryukhina, O., Satchell, K.J.F.

To be published.

Macromolecule Content

Total Structure Weight: 126.32 kDa
Atom Count: 6,252
Modeled Residue Count: 749
Deposited Residue Count: 1,098
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Fido domain-containing protein	A, B, C	366	Bordetella bronchiseptica	Mutation(s): 0 Gene Names: BB0907
UniProt
Find proteins for Q7VUH7 (Bordetella pertussis (strain Tohama I / ATCC BAA-589 / NCTC 13251)) Explore Q7VUH7 Go to UniProtKB: Q7VUH7
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q7VUH7
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
1PE Query on 1PE Download:Ideal Coordinates CCD File SDF format, chain E [auth A] MOL2 format, chain E [auth A] mmCIF format, chain E [auth A]	E [auth A]	PENTAETHYLENE GLYCOL C₁₀ H₂₂ O₆ JLFNLZLINWHATN-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Interactions & Density Focus chain E [auth A]
TAR Query on TAR Download:Ideal Coordinates CCD File SDF format, chain U [auth C] SDF format, chain T [auth C] SDF format, chain S [auth C] SDF format, chain M [auth B] SDF format, chain L [auth B] SDF format, chain K [auth B] SDF format, chain G [auth A] SDF format, chain F [auth A] MOL2 format, chain U [auth C] MOL2 format, chain T [auth C] MOL2 format, chain S [auth C] MOL2 format, chain M [auth B] MOL2 format, chain L [auth B] MOL2 format, chain K [auth B] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] mmCIF format, chain U [auth C] mmCIF format, chain T [auth C] mmCIF format, chain S [auth C] mmCIF format, chain M [auth B] mmCIF format, chain L [auth B] mmCIF format, chain K [auth B] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A]	F [auth A] G [auth A] K [auth B] L [auth B] M [auth B] F [auth A], G [auth A], K [auth B], L [auth B], M [auth B], S [auth C], T [auth C], U [auth C]	D(-)-TARTARIC ACID C₄ H₆ O₆ FEWJPZIEWOKRBE-LWMBPPNESA-N		Interactions Focus chain F [auth A] Focus chain G [auth A] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth B] Focus chain S [auth C] Focus chain T [auth C] Focus chain U [auth C] Interactions & Density Focus chain F [auth A] Focus chain G [auth A] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth B] Focus chain S [auth C] Focus chain T [auth C] Focus chain U [auth C]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain V [auth C] SDF format, chain H [auth A] MOL2 format, chain V [auth C] MOL2 format, chain H [auth A] mmCIF format, chain V [auth C] mmCIF format, chain H [auth A]	H [auth A], V [auth C]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Focus chain V [auth C] Interactions & Density Focus chain H [auth A] Focus chain V [auth C]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain R [auth B] SDF format, chain Q [auth B] SDF format, chain P [auth B] SDF format, chain O [auth B] SDF format, chain N [auth B] SDF format, chain J [auth A] SDF format, chain I [auth A] MOL2 format, chain R [auth B] MOL2 format, chain Q [auth B] MOL2 format, chain P [auth B] MOL2 format, chain O [auth B] MOL2 format, chain N [auth B] MOL2 format, chain J [auth A] MOL2 format, chain I [auth A] mmCIF format, chain R [auth B] mmCIF format, chain Q [auth B] mmCIF format, chain P [auth B] mmCIF format, chain O [auth B] mmCIF format, chain N [auth B] mmCIF format, chain J [auth A] mmCIF format, chain I [auth A]	I [auth A] J [auth A] N [auth B] O [auth B] P [auth B] I [auth A], J [auth A], N [auth B], O [auth B], P [auth B], Q [auth B], R [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain I [auth A] Focus chain J [auth A] Focus chain N [auth B] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B] Interactions & Density Focus chain I [auth A] Focus chain J [auth A] Focus chain N [auth B] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B]
NA Query on NA Download:Ideal Coordinates CCD File SDF format, chain D [auth A] MOL2 format, chain D [auth A] mmCIF format, chain D [auth A]	D [auth A]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Interactions & Density Focus chain D [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.95 Å
R-Value Free: 0.207 (Depositor), 0.203 (DCC)
R-Value Work: 0.178 (Depositor), 0.177 (DCC)
R-Value Observed: 0.179 (Depositor)

Space Group: P 6₅ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 149.971	α = 90
b = 149.971	β = 90
c = 371.921	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
PDB_EXTRACT	data extraction
HKL-3000	data reduction
HKL-3000	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-10-30

Deposition Author(s):

Brunzelle, J.S.

Satchell, K.J.F.

Center for Structural Biology of Infectious Diseases (CSBID)

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	HHSN272201700060C

Revision History (Full details and data files)

Version 1.0: 2024-10-30
Type: Initial release
