8THR

Structure of the human vesicular monoamine transporter 2 (VMAT2) bound to tetrabenazine in an occluded conformation

• PDB DOI: https://doi.org/10.2210/pdb8THR/pdb
• EM Map EMD-41269: EMDB EMDataResource

• Classification: TRANSPORT PROTEIN
• Organism(s): Aequorea victoria, Homo sapiens, Vicugna pacos
• Expression System: Homo sapiens
• Mutation(s): No
• Membrane Protein: Yes  PDBTMMemProtMD


• Deposited: 2023-07-17 Released: 2023-10-25
• Deposition Author(s): Dalton, M.P., Coleman, J.A.
• Funding Organization(s): Not funded

---

Experimental Data Snapshot

• Method: ELECTRON MICROSCOPY
• Resolution: 3.12 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Literature

Structure of the human vesicular monoamine transporter 2 (VMAT2) bound to tetrabenazine in an occluded conformation

Dalton, M.P., Coleman, J.A.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by (software)

Biological Assembly Evidence: electron microscopy

Macromolecule Content

• Total Structure Weight: 94.17 kDa
• Atom Count: 2,937
• Modelled Residue Count: 389
• Deposited Residue Count: 858
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
fluorescent protein mVenus,Synaptic vesicular amine transporter,GFP nano body,Synaptic vesicular amine transporter,Synaptic vesicular amine transporter	A	858	Aequorea victoria, Homo sapiens, Vicugna pacos This entity is chimeric	Mutation(s): 0  Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for Q05940 (Homo sapiens) Explore Q05940  Go to UniProtKB:  Q05940
PHAROS:  Q05940 GTEx:  ENSG00000165646

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
EBZ (Subject of Investigation/LOI)	B [auth A]	(3S,5R,11bS)-9,10-dimethoxy-3-(2-methylpropyl)-1,3,4,6,7,11b-hexahydro-2H-pyrido[2,1-a]isoquinolin-2-one C19 H27 N O3 MKJIEFSOBYUXJB-HOCLYGCPSA-N

Experimental Data & Validation

Experimental Data

• Method: ELECTRON MICROSCOPY
• Resolution: 3.12 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX	1.2
RECONSTRUCTION	cryoSPARC	4.2.1

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2023-10-25
Deposition Author(s): Dalton, M.P., Coleman, J.A.

---

Funding Organization	Location	Grant Number
Not funded		--

Revision History

• Version 1.0: 2023-10-25
  Type: Initial release
