8T12

Cryo-EM structure of DENV2 NS5 in complex with human STAT2 with the N-terminal domain of STAT2 ordered.

• PDB DOI: https://doi.org/10.2210/pdb8T12/pdb
• EM Map EMD-40952: EMDB EMDataResource

• Classification: IMMUNE SYSTEM/VIRAL PROTEIN
• Organism(s): Homo sapiens, dengue virus type 2
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2023-06-01 Released: 2024-01-17
• Deposition Author(s): Biswal, M., Lu, J., Song, J.
• Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

---

Experimental Data Snapshot

• Method: ELECTRON MICROSCOPY
• Resolution: 3.34 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Literature

Cryo-EM structure of DENV2 NS5 in complex with human STAT2 with the N-terminal domain of STAT2 ordered.

Biswal, M., Lu, J., Song, J.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 2-mer - A1B1

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: electron microscopy

Macromolecule Content

• Total Structure Weight: 201.42 kDa
• Atom Count: 10,813
• Modelled Residue Count: 1,343
• Deposited Residue Count: 1,751
• Unique protein chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Signal transducer and activator of transcription 2	A	851	Homo sapiens	Mutation(s): 0  Gene Names: STAT2
UniProt & NIH Common Fund Data Resources
Find proteins for P52630 (Homo sapiens) Explore P52630  Go to UniProtKB:  P52630
PHAROS:  P52630 GTEx:  ENSG00000170581

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Non-structural protein 5	B	900	dengue virus type 2	Mutation(s): 0
UniProt
Find proteins for Q91H74 (dengue virus type 2) Explore Q91H74  Go to UniProtKB:  Q91H74

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ZN (Subject of Investigation/LOI)	C [auth B], D [auth B]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: ELECTRON MICROSCOPY
• Resolution: 3.34 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2024-01-17
Deposition Author(s): Biswal, M., Lu, J., Song, J.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	--

Revision History

• Version 1.0: 2024-01-17
  Type: Initial release
