 8SRN | pdb_00008srn

De novo designed transmembrane antiparallel homo-dimer G-X6-G 01322-42


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.27 Å
  • R-Value Free:
    0.254 (Depositor), 0.265 (DCC)
  • R-Value Work:
    0.253 (Depositor), 0.259 (DCC)
  • R-Value Observed:
    0.253 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 8SRN

This is version 1.1 of the entry. See complete history.

Literature

Design principles of the common Gly-X6-Gly membrane protein building block.

Golden, K., Avarvarei, C., Anderson, C.T., Holcomb, M., Tang, W., Dai, X., Zhang, M., Mailie, C.A., Sanchez, B.B., Chen, J.S., Forli, S., Mravic, M.

(2025) Proc Natl Acad Sci U S A 122: e2503134122-e2503134122

  • DOI: https://doi.org/10.1073/pnas.2503134122
  • Primary Citation Related Structures:
    8SRN

  • PubMed Abstract:

    Protein behavior in lipids is poorly understood and inadequately represented in current computational models. Design and prediction abilities for bilayer-embedded molecular structures may be improved by characterizing membrane proteins' most frequent, favored structural features to glean both context-specific and general principles. We used protein design to proactively interrogate the sequence-structure relationship and stabilizing atomic details of two highly prevalent antiparallel transmembrane (TM) motifs with Small-X 6 -Small consensus sequences. A fragment-based data-mining and sequence statistical inference method including cross-evolutionary structure-aligned covariance enabled engineering of de novo TM protein assemblies by successfully encoding Gly-X6-Gly and Ala-X6-Ala building blocks. A highly stable glycine-based design's X-ray structure hosts Cα-H∙∙∙O = C H-bonding alongside extensive backbone-directed van der Waals packing, idealizing features of this motif in Nature. Data-driven design navigates sequence space to directly inquire upon how to encode and stabilize vital membrane protein structural elements, facilitating efficacious construction of lipid-embedded architectures of increasing complexity.


  • Organizational Affiliation:
    • Department of Integrative Structural and Computational Biology, The Scripps Research Institute, La Jolla, CA 92037.

Macromolecule Content

  • Total Structure Weight: 18.98 kDa
  • Atom Count: 1,034
  • Modeled Residue Count: 146
  • Deposited Residue Count: 180
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Gx6G_denovo_design_01322-42
A, B, C, D, E
A, B, C, D, E, F
30synthetic constructMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.27 Å
  • R-Value Free:  0.254 (Depositor), 0.265 (DCC)
  • R-Value Work:  0.253 (Depositor), 0.259 (DCC)
  • R-Value Observed: 0.253 (Depositor)
Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 54.008α = 90
b = 71.408β = 90
c = 101.064γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
SCALEPACKdata scaling
HKL-3000data reduction
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Other privateUnited States--

Revision History  (Full details and data files)

  • Version 1.0: 2024-09-04
    Type: Initial release
  • Version 1.1: 2026-02-11
    Changes: Database references, Structure summary
